Артикул
Название
Примечание
Количество
1
31-1585
FITTING
ELBOW - 90 degree, 1/2 NPT x 1/2 inch NPT
1шт.
2
31-1267
SHUT-OFF VALVE
VALVE - shut off
2шт.
3
31-449
HYD CONNECTOR,7/8"-14, 37 Degree x 1/2"-14, NPTF
CONNECTOR - straight, 1/2 NPT x 7/8 inch thread
1шт.
6
REF
INSTRUCTION
FILTER ASSEMBLY - fuel (See Figure: 3-22)
1шт.
7
REF
INSTRUCTION
HOSE - fuel supply (See Page 3-7)
1шт.
8
1-2056
ELBOW
CONNECTOR - 45 degree, 7/8 x 7/8 inch thread
1шт.
9
31-345
FITTING
CONNECTOR - straight, 1/2 NPT x 1/2 inch NPT
1шт.
10
31-340
ELBOW,90 Degree, 7/8"-14, 37 Degree x 1/2"-14, NPTF
CONNECTOR - 90 degree, 1/2 NPT x 7/8 inch thread
1шт.
11
31-2780
HOSE
- fuel return
1шт.
14
31-619
ELBOW
CONNECTOR - straight, 3/4 x 3/4 inch thread
1шт.
15
308576R1
CLAMP
- hose
6шт.
16
299567C1
CLAMP,7/8", Insul, 3/8" Bolt
- hose
7шт.
17
129-103
NUT,Hex, 3/8" - 16, Gr 5
NUT, 3/8"-16, G5
6шт.
18
113-207
BOLT,Hex, 3/8" - 16 x 1", Gr 5
1шт.
19
19-341
LOCK NUT,3/8" - 16, GB
NUT - hex, lock, 3/8 inch NC
1шт.
20
22-824
CABLE TIE,3/16" x 7 1/4"
STRAP - nylon
2шт.
24
31-1536
BREATHER
VENT - breather, fuel tank
1шт.
Выбрано товаров: 19
