Запчасти Case IH ST280 (03-07) - A/C AND HEATER PLUMBING, 3306 ENGINE, LATER STYLE (03) - Climate Control

Схема запчастей Case IH ST280 - (03-07) - A/C AND HEATER PLUMBING, 3306 ENGINE, LATER STYLE (03) - Climate Control
25
20
13
1
16
14
19
11
9
29
17
22
4
7
24
6
12
5
22
28
30
18
12a
8
15
2
7
14
3
10
23
7
21
26
27
31
2
7

Артикул

Название

Примечание

Количество

1

25-380

HOSE

1шт.

2

31-1350

A/C HOSE,7.94mm ID x 2819.4mm L

Hose

1шт.

3

31-1351

A/C HOSE,0.31" ID x 22.00" , SAE J516 Type A

0.31" ID x 22.00", SAE J516 Type A

1шт.

4

31-1299

HOSE

1шт.

5

31-1352

HOSE,0.63" ID x 16.00"

1шт.

6

31-1067

HOSE,0.63" ID x 36.00"

0.63" ID x 36.00"

1шт.

7

25-285

SQUARE NUT,Sq, 5/16"-18

Clamp

6шт.

8

25-378

HEATER TUBE,0.625" OD, 32" Length

Tube

1шт.

9

25-379

HEATER TUBE,0.625" OD, 42, 0.81" Length

Tube

1шт.

10

32-1000

CLAMP

1шт.

11

19-550

BOLT,Hex, M16 x 35mm, Cl 10.9

Capscrew, 1/4 NC x 1-1/2

1шт.

12

25393

Bracket (all ST 270) (ST 250 after S/N Break w/DI Engine)

1шт.

12a

25-1001

Bracket (all ST 225) (ST 250 before S/N Break)

1шт.

13

22-632

CLIP

Clamp

1шт.

14

280129

NUT,1/4"-20

1/4 NC

1шт.

15

19-117

LOCK WASHER,3/8"

3/8"

1шт.

16

19-211

CAPSCREW,1/4" - 20 x 1 1/4", Gr 5

1/4 NC x 1-14

2шт.

17

19-5381

NUT

1/4 UNC

2шт.

18

19-14

BOLT,Hex, 3/8" - 24 x 2", Gr 5

Capscrew, 3/8 NF x 2

1шт.

19

19-107

WASHER

3/8

1шт.

20

25-48

HOSE CLAMP

Clamp

1шт.

21

31-1275

SHUT-OFF VALVE

Valve, Truck

1шт.

22

1-483

Tube 0.75" ID, 0.438" OD, 1.12" Length

1шт.

23

31-319

HYD CONNECTOR,7/8"-14, 37 Degree x 3/8"-18, NPTF

Connector

1шт.

24

31-1295

HOSE,0.63" ID x 46.00"

(31-1293) 0.63" ID x 46.00"

1шт.

Superseded, Old P/N is not used any longer, the new P/N is to be used in ALL cases. Old P/N should be removed from exisiting inventory. it is recommended that the old part not be used under any circumstances.

1шт.

25

31-1296

Barbed Fitting

1шт.

26

276-1478

SELF-TAP SCREW,Hex Hd, 1/4" x 1/2"

Screw, Tapping, 1/4 NC x 1/2

2шт.

27

1-7778

AIR CONDITIONER

Receiver, Drier

1шт.

28

25-1002

SWITCH

(Low Pressure)

1шт.

29

1-8563

CLAMP BRACKET

Bracket

1шт.

30

25-196

Condenser 3/8"-24, G5, Thk

1шт.

2-3370T1

CONDENSER

(interchangeable w/25-196)

1шт.

31

51-243

HOLDER

Clamp

1шт.

Выбрано товаров: 34
