Запчасти Case IH ST210 (08-11) - STEERING CYLINDER AND MOUNTING (07) - HYDRAULICS

1

18-1148

FLYWHEEL WITH GEAR

CYLINDER ASSY.

1шт.

The only difference between cylinders P/N 18-1148 and P/N 18-1297 is the nut (Ref. 5). When using wide tires in a dual arrangement the P/N 18-1297 cylinder and 18-928 nut must be used.

1шт.

18-1297

CYLINDER

ASSY.

1шт.

The only difference between cylinders P/N 18-1148 and P/N 18-1297 is the nut (Ref. 5). When using wide tires in a dual arrangement the P/N 18-1297 cylinder and 18-928 nut must be used.

1шт.

2

18-1002

ROD

ASSEMBLY

1шт.

3

18-1001

GUIDE

ROD GUIDE

1шт.

4

18-1000

PISTON

1шт.

5

19-98

NUT,1"-14, G5

1 UNF

1шт.

The only difference between cylinders P/N 18-1148 and P/N 18-1297 is the nut (Ref. 5). When using wide tires in a dual arrangement the P/N 18-1297 cylinder and 18-928 nut must be used.

1шт.

18-928

STOP

NUT, 1 UNF

1шт.

The only difference between cylinders P/N 18-1148 and P/N 18-1297 is the nut (Ref. 5). When using wide tires in a dual arrangement the P/N 18-1297 cylinder and 18-928 nut must be used.

1шт.

6

18-999

TUBE

SHELL

1шт.

7

18-1012

SEAL PACKAGE

SEAL KIT, complete

1шт.

8

3-1001

PLATE

MOUNT PLATE ASSY.

4шт.

9

19-216

BOLT,Hex, 3/4" - 10 x 3", Gr 5

CAPSCREW, 3/4 x 3 UNC

12шт.

10

19-112

WASHER,3/4"

3/4

12шт.

11

19-85

LOCK NUT

3/4 UNC

12шт.

12

19-862

BOLT,Hex, 1 1/8" - 7 x 4", Gr 8

CAPSCREW, 1-1/8 x 4 UNC

4шт.

13

19-863

LOCK NUT,1 1/8"-7, GC

NUT, 1-1/8 UNC

4шт.
