Запчасти Case IH KP-525 (01-05) - STEERING CONTROLS & MOUNTING (10) - CAB

1

18-511

MOUNTING PARTS

Rubber Mount

4шт.

2

47-4508

FOAM

Seal

1шт.

3

19-5525

Capscrew

4шт.

4

2-3813T1

COLLAR

1шт.

5

1-3417

STEERING ASSY

Steering Shaft

1шт.

6

7803464

CARRIAGE BOLT,7/16" - 20 x 1.88"

Capscrew

1шт.

7

60-1469T2

BRACKET

Mount Plate

1шт.

8

60-1471T1

BRACKET

Mount Plate

1шт.

9

19-341

LOCK NUT,3/8" - 16, GB

2шт.

10

19-107

WASHER

2шт.

11

19-6

BOLT,5/16" - 18 x 3/4", Gr 5

Capscrew

4шт.

12

Steering Column Assy (Metric Thread Hardware) (see fig. 1-6)

1шт.

13

47-4512

PLATE

1шт.

14

2-3769T1

PLATE

1шт.

15

19-717

BOLT,Hex, 1/4" - 20 x 5/8", Gr 5, Full Thd

Capscrew

2шт.

16

1-3414T1

SHAFT

Spline Shaft

1шт.

17

7810280

NUT

1шт.

18

231-1445

NUT,5/16"-18, GB

NUT, LOCK, 5/16"-18, GB

4шт.

19

19-891

HEX SOC SCREW,1/4"-20 x 1/2"

Socket Head Capscrew

2шт.

20

1-3412

CLAMP

1шт.

21

19-700

WASHER,5/16"

1шт.

22

11500763

BOLT,Hex, M8 x 1.25 x 16mm, Cl 8.8, Full Thd

Capscrew (metric)

4шт.

23

18-1567T1

CONTROL LEVER

Tilt Control Lever

1шт.

24

1-4188T1

CONTROL LEVER

Turn Signal Lever

1шт.

2-3755T92

STEERING WHEEL

Assy, Includes: Ref. 25 - 30

1шт.

25

60-1827T2

WHEEL (STEERING)

Steering Wheel

1шт.

26

60-1828T1

CAP

Upper Hub Cover

1шт.

27

60-1829T1

COVER

Lower Hub Cover

1шт.

28

19-5791

SELF-TAP SCREW,Cross Pan Hd, #6 x 1 1/4"

Tapping Screw

2шт.

29

60-1830T1

RETAINER

Spring Retainer

1шт.

30

60-1831T1

SPRING

1шт.

31

18-1570

RING, SNAP

Retainer

1шт.

32

60-1951T1

CONTROL LEVER

Release Lever

1шт.

33

18-1565

LOCK SCREW,5/16" - 18 x 0.95"

Locking Screw

1шт.

34

260-14436

SELF-TAP SCREW,Cross Pan Hd, #8 x 2 1/4"

Tapping Screw

1шт.

35

9414743

SCREW,Tap, Gr 5

Tapping Screw

3шт.

36

60-1820T1

SPRING

1шт.

37

60-1819T1

PLATE

Base Plate

1шт.

38

60-1821T1

CUPEL

Contact Cup

1шт.

39

60-1952T2

BUTTON

Horn Button

1шт.

40

2-3770T1

PLATE

1шт.

41

488-1104

SCREW,Cross Flat Hd, #10-32 x 1/4"

Machine Screw

2шт.

42

1-4464

LOCK

set (contains new keys and locks for Cab Doors & Steering Column)

1шт.

43

7809433

CLAMP

1шт.

44

19-151

LOCK PIN,1/4" x 1", Slotted

Pin, 1/4" x 1", Slotted

3шт.

45

19-5669

LOCK PIN,1/4" x 1 1/2", Slotted

Pin, 1/4" x 1 1/2", Slotted

1шт.

46

19-1026

JAM NUT,9/16" - 18, Gr 5

(incl with Ref. 12)

1шт.
