Артикул
Название
Примечание
Количество
1
20-1226T1
HARNESS
Main Cab Wire Harness
1шт.
2
1-7093
HARNESS
Cab Power Wire Harness
1шт.
3
20-1150T1
BLOCK
Junction Block
1шт.
4
19-5577
LOCK WASHER
Lock Washer (Brass)
2шт.
5
1-7096
GASKET
Junction Block Gasket
1шт.
6
436751
SCREW,Slotted Pan Hd, #10-32 x 5/8"
Machine Screw
2шт.
7
19-308
NUT,#10 - 32
10шт.
8
19-297
LOCK WASHER,#10
Washer, Lock, #10
2шт.
9
1-8578
COVER
Harness Connector Cover
1шт.
10
19-720
BOLT,1/4" - 20 x 3/4"
Capscrew
2шт.
11
31-2160
CLAMP
1шт.
12
22-823
MOUNT
Cable Tie Mount
2шт.
13
22-824
CABLE TIE,3/16" x 7 1/4"
STRAP, CABLE, 3/16" x 7 1/4"
2шт.
14
Audio Alarm (Fig. 2-17)
1шт.
16
1-3925
SOCKET
Wire & Socket Assy
2шт.
17
1-3934
HARNESS
Wire - Gauge Ground to Gauge Ground
2шт.
18
22-802
CABLE
Wire - Gauge Ground
1шт.
19
1-3932
HARNESS
Wire - Circuit Breaker
1шт.
22-678
BREAKER
Circuit Breaker Assy, consists of Ref. 20-30
1шт.
20
22-674
BRACKET
1шт.
21
22-675
BAR
Buss Bar (6 hole)
1шт.
22
22-676
BREAKER
Buss Bar (3 hole)
1шт.
23
22-677
BAR
Buss Bar (2 hole)
1шт.
24
22-809
BREAKER
Circuit Breaker (5 Amp)
1шт.
25
22-669
BREAKER
Circuit Breaker (6 Amp)
2шт.
27
22-671
BREAKER
Circuit Breaker (15 Amp)
5шт.
28
22-672
BREAKER
Circuit Breaker (20 Amp)
2шт.
29
22-673
BREAKER
Circuit Breaker (30 Amp)
1шт.
30
19-481
SERRATED NUT
Kep Nut
1шт.
31
1-3856
BREAKER
Circuit Breaker (5 Amp)
1шт.
32
19-282
LOCK NUT
1шт.
33
19-417
BOLT,Hex, 1/4" - 20 x 0.50", Gr 5, Full Thd
Capscrew
9шт.
34
22-792
SWITCH
Solenoid
1шт.
35
20-1411T1
CONNECTION,ELECTRIC
Solenoid
1шт.
36
20-1463T1
SWITCH
Assy (Brake Warning)
1шт.
37
22-108
FLASHER UNIT
Flasher
3шт.
38
22-112
BRACKET
Flasher Bracket
3шт.
2-3721T91
PLATE
Component Assy, consists of Ref. 39-51
1шт.
39
1-3864T1
LARGE PLATE
Bracket
1шт.
40
19-3041
SCREW,Hex Flg, #8 - 32 x 1 1/2", Gr 2
Capscrew
2шт.
41
193-1002
NUT,Keps, #8 - 32, w/ Ext Tooth LW
2шт.
42
1-3861
RELAY
(can be serviced w/Ref. 57 plus 35-1578T91 Relay Adapter Kit)
2шт.
43
1-3859
INSULATOR
Rectifier Insulator
1шт.
44
1-3860
ELECTRICAL WIRE
Wire - Rectifier
1шт.
45
19-5379
NUT
1шт.
46
1-3858
RESISTOR
(5 Ohm)
1шт.
47
1-3857
RESISTOR
(2 Ohm)
1шт.
48
1-3862
RECTIFIER
Assy
1шт.
49
19-5391
SCREW,Hex Flg, 1/4" - 20 x 1/2"
Capscrew
4шт.
50
19-76
NUT,1/4"-20, G5
6шт.
51
19-115
LOCK WASHER,1/4"
1/4"
6шт.
52
115772
NUT
(Brass)
2шт.
53
20-1250T1
ELECTRICAL WIRE
Wire - Dash Ground
1шт.
54
20-1628T1
HARNESS
Wire - Park Brake Switch
1шт.
55
20-1583T1
HARNESS
Tach Wire Harness
1шт.
56
20-1749T1
ELECTRICAL WIRE
Adapter Wire Harness
1шт.
57
1-7877
RELAY
(Ref. 42)
1шт.
35-1578T91
RELAY
Adapter Kit, consists of Ref. 58-62
1шт.
58
20-2131T1
HARNESS
Relay Harness
1шт.
60
159927
SCREW,Cross Pan Hd, #10 - 24 x 1/2"
1шт.
61
19-297
LOCK WASHER,#10
Washer, Lock, #10
1шт.
62
19-567
NUT,#10-24
1шт.
Выбрано товаров: 65
