Запчасти Case IH 9240 (9-116) - AIR CONDITIONER, COMPRESSOR MOUNTING AND DRIVE, 9240 TRACTOR, PRIOR TO P.I.N. JCB0028402 (09) - CHASSIS/ATTACHMENTS

1

2-5295T2

BRACKET

- compressor pivot

1шт.

2

425-118

NUT,1/2"-20, G5

- hex, 1/2 inch NF

2шт.

3

1-6899T1

BLOCK

- compressor belt adjusting

1шт.

4

22-1086T1

ROD

EYEBOLT, adjusting, compressor belt

1шт.

5

413-632

BOLT,Hex, 3/8" - 16 x 2", Gr 5

- hex, 3/8 NC x 2 inch

2шт.

9

231-4118

LOCK NUT,1/2"-13, GB

NUT - hex, self-locking, 1/2 inch NC

3шт.

10

90-6110T1

BRACKET

- compressor pivot, front

1шт.

11

19-454

SCREW,Hex, M10 x 34mm, Cl 8.8

BOLT - hex, 10 mm - 1.5 x 34 mm

5шт.

12

495-21044

WASHER,3/8"

(flat, 7/16 x 1 x 5/64 inch) 3/8"

5шт.

13

19-455

NUT

- hex, 10 mm - 1.5

5шт.

14

60-2921T94

AIRCOND. COMPRESSOR

ASSEMBLY - air conditioning, parts list Figure 9-122

1шт.

60-2921T94R

REMAN-A/C COMPRESSOR

9240 CASE IH STEIGER PRIOR TO P.I.N. JCB0028402 (10/90-10/94)

1шт.

60-2921T94C

CORE-A/C COMPRESSOR

Return Number

1шт.

19

40-1091

BOLT,Hex, M10 x 1.5 x 20mm, Gr 8.8

BOLT - hex, 10 - 1.5 x 20 mm

4шт.

20

492-11044

LOCK WASHER,7/16"

WASHER, LOCK, 7/16"

4шт.

21

413-880

BOLT,Hex, 1/2" - 13 x 5", Gr 5

- hex, 1/2 NC x 5 inch

1шт.

22

90-7339T1

MOUNTING PARTS

MOUNT - compressor

1шт.

23

6-1451

V-BELT,0.53" W x 51.75" L

0.53" W x 51.75", Compressor, Air conditioning

1шт.

24

495-21056

WASHER,1/2"

- flat, 9/16 x 1-3/8 x 7/64 inch

3шт.

25

70-5846T1

GRIP

- handle

1шт.

30

60-2921T94

AIRCOND. COMPRESSOR

ASSEMBLY - air conditioning, parts list Figure 9-122, P.I.N. JCB0028402 and after

1шт.

60-2921T94R

REMAN-A/C COMPRESSOR

9240 CASE IH STEIGER 4WD TRACTOR, AIR CONDITIONER, COMPRESSOR MOUNTING AND DRIVE, 9240 TRACTOR, PRIOR TO P.I.N. JCB0028402, ASSEMBLY - air conditioning, P.I.N. JCB0028402 and after (10/90-10/94)

1шт.

60-2921T94C

CORE-A/C COMPRESSOR

Return Number

1шт.

31

2-5295T2

BRACKET

- compressor pivot, rear, P.I.N. JCB0028402 and after

1шт.

32

614-10035

BOLT,Hex, M10 x 1.5 x 35mm, Cl 8.8, Full Thd

- hex, full threads, 10 - 1.5 x 35 mm, P.I.N. JCB0028402 and after

5шт.

33

495-21044

WASHER,3/8"

(flat, 7/16 x 1 x 5/64 inch), P.I.N. JCB0028402 and after 3/8"

6шт.

34

825-1410

NUT,M10, Cl 8

P.I.N. JCB0028402 and after M10, Cl 8

5шт.

35

90-7591T1

BRACKET

- compressor mounting, P.I.N. JCB0028402 and after

1шт.

36

90-7587T1

ADJUSTING PLATE

STRAP - adjusting, P.I.N. JCB0028402 and after

1шт.

37

426-620

BOLT,Hex, 3/8" - 16 x 1-1/4", Gr 8

P.I.N. JCB0028402 and after Hex, 3/8"-16 x 1 1/4", G8, Full Thd

2шт.

38

19-341

LOCK NUT,3/8" - 16, GB

NUT - hex, self-locking, 3/8 inch NC, P.I.N. JCB0028402 and after

2шт.

41

6-1451

V-BELT,0.53" W x 51.75" L

0.53" W x 51.75", Compressor, Air conditioning, P.I.N. JCB0028402 and after

1шт.

42

90-7592T1

MOUNTING PARTS

MOUNT - compressor, no longer available, order 90-7754T1 mount, P.I.N. JCB0028402 and after

1шт.

43

426-880

BOLT,Hex, 1/2" - 13 x 5", Gr 8

- hex, 1/2 NC x 5 inch, grade 8, P.I.N. JCB0028402 and after

1шт.

44

231-4118

LOCK NUT,1/2"-13, GB

NUT - hex, self-locking, 1/2 inch NC, P.I.N. JCB0028402 and after

1шт.

45

614-10020

BOLT,Hex, M10 x 1.5 x 20mm, Cl 8.8, Full Thd

P.I.N. JCB0028402 and after Hex, M10 x 20, 8.8, Full Thd

4шт.

46

492-11044

LOCK WASHER,7/16"

WASHER, LOCK, , P.I.N. JCB0028402 and after 7/16"

4шт.

47

70-5846T1

GRIP

- handle, P.I.N. JCB0028402 and after

1шт.
