Артикул
Название
Примечание
Количество
1989021C2
ENGINE ASSEMBLY
- complete, new, Includes: all parts except starter, alternator, fan, fan belt, air cleaner, muffler and exhaust pipe, for service order 1989099C2 basic engine shown on Figure 2-048
1шт.
87448684
REMAN-SHORT ENGINE
Reman For New P/N 1989021C2
1шт.
6830SHBC
CORE-SHORT ENGINE
Return Part Number Short Block
1шт.
1989099C1
BASIC ENGINE
ENGINE ASSEMBLY - basic, new
1шт.
Includes: all parts except: starter, alternator, fan, fan belt, fan bracket, air cleaner, muffler, exhaust manifold and pipe, flywheel and housing, oil fill and dipstick, fuel injection pump, injectors and lines, front crank pulley, belt tensioner and turbocharger, uses Ref. 1A, sleeve and Ref. 3A, piston shown on Figure 2-066
1шт.
47466039R
REMAN-BASIC ENGINE
Remanufactured Basic Engine Assembly, assembly includes short block assembly, cylinder head, valve cover, front cover, oil pan, water pump, thermostat and gasket kit to transfer trim parts
1шт.
47466039C
CORE-BASIC ENGINE
Return Part Number
1шт.
JR921839
BLOCK
Assembly - short, remanufactured, component parts shown on this Figure do not apply to the remanufactured assembly, Includes: Ref. 1 - 9
1шт.
JC921057
CORE-SHORT ENGINE
Return Part Number - use this part number to return block core for credit when using a remanufactured assembly
1шт.
J921058
CRANKCASE
BLOCK ASSEMBLY - short, engine, new, Includes: stripped block, pistons, connecting rods and bearings, crankshaft and bearings, uses item 1 sleeve and pistons stamped 8750, 9930, 9565 or 3164, shown on Figure 2-064, Includes: Ref. 1 - 9
1шт.
1
J920036
CYLINDER BLOCK
BLOCK ASSEMBLY - cylinder, stripped, new, order: Ref. 10 - 20, Includes: Ref. 2 - 9
1шт.
Order Ref. 10 - 20 on Figure 2-046 when ordering J920036 stripped block.
1шт.
2
J917313
BEARING CAP
CAP - bearing, main
7шт.
3
J916369
FLANGE BOLT,Hex, M14 x 2 x 128mm, Cl 10.9
SCREW, , Main bearing cap to block Hex Flg Hd, M14 x 128
14шт.
4
J901685
BUSHING
- camshaft, See Figure 2-042, Ref. 6
7шт.
5
A77782
PLUG
- expansion, 58 mm OD
1шт.
6
A77586
PLUG
- expansion, 28.9 mm OD
1шт.
7
A77506
PLUG
- expansion, 21 mm
4шт.
8
J905401
PLUG
- expansion, 35 mm OD
3шт.
9
A77439
PLUG
- expansion, 22 mm OD
1шт.
A77716
BLOCK
KIT - block hardware, no longer available, order components separately, Includes: Ref. 10 - 20
1шт.
Order Ref. 10 - 20 on Figure 2-046 when ordering J920036 stripped block.
1шт.
10
A77530
PLUG
- expansion, 30 mm OD
2шт.
10a
A77439
PLUG
- expansion, not used in this application
1шт.
12
J901846
PIN,12.01mm OD x 24mm L
- dowel
4шт.
13
J906619
PLUG,1/8" - 27
- hex, 1/8 inch PT
6шт.
14
A77429
PLUG
- hex socket, 1/2 inch PT
4шт.
15
A77505
PLUG
- hex socket, 3/4 inch PT
2шт.
16
A77533
PLUG
- hex socket, 1 inch PT
1шт.
17
J919003
NOZZLE INJECTION
NOZZLE - cooling, piston
12шт.
18
J900257
PIN,10.01mm OD x 16mm L
- dowel, 16 mm
2шт.
19
A77425
DRAIN VALVE
VALVE - drain, coolant
1шт.
20
J903744
PIPE FITTING,22.42 mm ID x 28 mm OD x 90.2, 64 mm L
TUBE - turbocharger drain
1шт.
21
J920762
ELBOW
HOSE - elbow, water, replaces J909389 hose
1шт.
22
J918521
HOSE CLAMP,59mm - 83mm
CLAMP - hose, adjustable, 1-13/16 - 2-3/4
1шт.
23
J905408
TUBE,35.13 mm ID x 52.39 mm OD x 100 mm L
- filler, oil
1шт.
24
A77424
FILLER CAP
CAP - filler
1шт.
25
J905425
TUBE,9.52 mm OD x 93 mm L
- dipstick, oil
1шт.
This is a dipstick tube hole if an expansion plug is needed order P/N J900955, which is a 10 mm plug
1шт.
J900955
PLUG
expansion, 10 mm
1шт.
26
J908772
DIPSTICK
- oil gauge, 298 mm long
1шт.
A77595
KIT
- engine block heater, Includes: Ref. 27 - 29
1шт.
27
J905113
CABLE
- heater, engine block
1шт.
28
NSS
NOT SOLD SEPARAT
ELEMENT - heater, 120 volt, 1000 watts, engine block
1шт.
29
J910517
O-RING
- heater element, engine block
1шт.
Выбрано товаров: 46
