Запчасти Case IH 9230 (9-024) - FRONT FRAME (09) - CHASSIS/ATTACHMENTS

1

70-6316T1

FRAME ASSY

FRAME - front, replaces 70-5901T1, also order 35-1915T91 Articulation Stop Kit, See Figure 5-022, Ref. 55 - 56, prior to P.I.N. JCB0031475

1шт.

1

70-6510T2

FRAME

- front, P.I.N. JCB0031475 and after

1шт.

Note , the weldment angle plate on end of frame where Item # 1 is pointed is part no. 70-4442t2

1шт.

2

70-6323T2

STEP

- cab access

1шт.

3

496-11053

WASHER,17/32" x 1 1/16" x .095", HDN

15шт.

4

425-108

NUT,1/2" - 13, Gr 5

NUT, , Hex 1/2"-13, G5

15шт.

5

70-3158T1

HINGE

step swing out, no longer available, order 70-3158T2 hinge and 425-108 hex nuts

2шт.

6

496-11053

WASHER,17/32" x 1 1/16" x .095", HDN

4шт.

7

326-816

BOLT,Hex, 1/2" - 13 x 1", Gr 8

4шт.

8

70-3158T2

HINGE

- swing out step

1шт.

If replacing 70-3158T1 hinge with 70-3158T2, also order 425-108 hex nuts.

1шт.

10

70-4621T2

BUSHING,44.5mm ID x 57.12mm OD x 25.4mm L

pivot, frame rear

4шт.

11

219-1

LUBE NIPPLE,1/8" - 27 NPTF

FITTING - grease, straight, 1/8 PT x 21/32 inch

2шт.

12

70-2142T3

STEP

- lower front

1шт.

13

426-824

BOLT,Hex, 1/2" - 13 x 1-1/2", Gr 8

- hex, 1/2 NC x 1-1/2 inch, grade 8

4шт.

15

70-5517T1

BUSHING,38.09mm ID x 54.74mm OD x 33.33mm L

BEARING - self-aligning, steering cylinder pivot

2шт.

16

31-2787

GROMMET

TRIM - edge, 7 inch (178 mm) long, cut from 31-1785 bulk trim, see below

1шт.

35-1742T91

BOX, TOOL

KIT - tool box, order individual components, Includes: Ref. 18 - 22

1шт.

18

A181436

TOOL BOX

BOX, TOOL

1шт.

19

A181434

SUPPORT

BRACKET - mounting, tool box

1шт.

20

425-108

NUT,1/2" - 13, Gr 5

NUT, , Hex 1/2"-13, G5

2шт.

21

495-21056

WASHER,1/2"

- flat, 9/16 x 1-3/8 x 7/64 inch

2шт.

22

426-820

BOLT,Hex, 1/2" - 13 x 1-1/4", Gr 8

2шт.

23

70-6123T1

PLATE

- mounting, tool box

1шт.

24

50-2898T1

TUBE

BRACE - frame

1шт.

25

50-2962T1

CONDUIT

93 inch long, cut from S119717X bulk conduit, see below

1шт.

26

22-824

CABLE TIE,3/16" x 7 1/4"

STRAP - tie, 7 inch long

4шт.

27

426-616

BOLT,Hex, 3/8" - 16 x 1", Gr 8

2шт.

28

495-21044

WASHER,3/8"

(flat, 7/16 x 1 x 5/64 inch) 3/8"

2шт.

29

425-106

NUT,3/8"-16, Cl 5

2шт.

31-1785

GROMMET

TRIM - edge, bulk, 120 inch (3048 mm) long

1шт.

S119717X

CONDUIT

- bulk, 1 (25) ID x 192 inch (4877 mm) long

1шт.
