Запчасти Case IH 9230 (5-018) - STEERABLE AXLE MOUNTING, IF EQUIPPED (05) - STEERING

1

70-5463T1

BASE

PLATE - frame base

1шт.

2

70-5514T1

AXLE

PLATE - axle base

1шт.

Ref #2 - The bearing ring part of Ref #2 is 70-5242T1

1шт.

3

70-5465T1

LARGE PLATE

PLATE - clamp

1шт.

4

70-5298T1

PLATE

- bearing

4шт.

5

70-5296T1

BRACKET

- mounting, steering cylinder

2шт.

6

70-4557T1

BALL JOINT

BUSHING - seal aligning, 1-1/4 inch

3шт.

7

70-4541T2

BUSHING,48 mm OD x 0.98"

- nylatron

2шт.

8

70-5294T1

PLATE

- bearing

1шт.

9

70-5287T1

PLATE

- bearing

2шт.

10

70-5299T1

SEAL

- dust, 112 inch (Order 2-7445T1 and, Serial Range: cut-length)

2шт.

14

70-5301T1

SPACER

- mounting

8шт.

15

326-1288

BOLT,Hex, 3/4" - 10 x 5-1/2", Gr 8

13шт.

16

19-5723

WASHER

- flat, 3/4 x 1-1/2 x 5/32 inch

14шт.

17

495-11081

WASHER,3/4", SAE

15шт.

18

232-41112

NUT,3/4"-10, GC

NUT, LOCK, 3/4"-10, GC

4шт.

21

413-1272

BOLT,Hex, 3/4" - 10 x 4-1/2", Gr 5

- hex, 3/4 NC x 4-1/2 inch

7шт.

22

425-1012

NUT,3/4"-10, G5

- hex, 3/4 inch NC

7шт.

23

232-41112

NUT,3/4"-10, GC

NUT, LOCK, 3/4"-10, GC

5шт.

24

275635R1

BOLT,Hex, 1/2" - 13 x 3", Gr 8

- hex, 1/2 NC x 3 inch, grade 8

8шт.

25

60-6316T1

LARGE PLATE

PLATE, Mounting, Potentiometer, See Figure 5-026

1шт.

28

70-4636T1

AXLE

PLATE - mounting, axle

2шт.

29

26720R1

BOLT,Hex, 1" - 8 x 5", Gr 8

- hex, 1 NC x 5 inch, grade 8

8шт.

30

19-5685

WASHER

- flat, 1 x 2 x 3/8 inch

4шт.

31

232-41116

LOCK NUT,1"-8, GC

NUT, LOCK, 1"-8, GC

8шт.

32

90-6950T1

DIPSTICK

INDICATOR - axle

1шт.

33

90-6949T1

FORK

INDICATOR - frame

1шт.

34

426-1232

BOLT,Hex, 3/4" - 10 x 2", Gr 8

2шт.

35

70-5302T1

CAP

PLUG - hole

2шт.
