Запчасти Case IH 9210 (7-010) - BRAKE SYSTEM, WITH SINGLE CALIPER (07) - BRAKES

1

90-6479T1

BRAKE DISC

DISC - brake, 15 inch diameter

1шт.

2

328-824

BOLT,Hex, 1/2" - 20 x 1-1/2", Gr 8

8шт.

3

REF

INSTRUCTION

CALIPER ASSEMBLY - brake parts list Figures 7-014 or 7-015A

1шт.

4

326-1032

BOLT,Hex, 5/8" - 11 x 2", Gr 8

2шт.

5

90-6481T1

SUPPORT

MOUNT - caliper assembly

2шт.

6

326-1028

BOLT,Hex, 5/8" - 11 x 1-3/4", Gr 8

4шт.

7

90-6466T3

BRACKET

- cable guide

1шт.

8

326-1036

BOLT,Hex, 5/8" - 11 x 2-1/4", Gr 8

2шт.

9

90-4030T1

SUPPORT

BRACKET - actuating, park brake

1шт.

10

326-516

BOLT,Hex, 5/16" - 18 x 1", Gr 8

2шт.

11

231-1445

NUT,5/16"-18, GB

NUT - hex, self-locking, 5/16 inch NC

2шт.

17

326-620

BOLT,Hex, 3/8" - 16 x 1-1/4", Gr 8

1шт.

18

231-1446

NUT,3/8" - 16, Gr 5

NUT - hex, self-locking, 3/8 inch NC

1шт.

19

REF

INSTRUCTION

SPRING - parking brake return, See Figures 7-014 or 7-015A

1шт.

20

90-7546T1

TUBE,.25" OD

- caliper assembly to master brake valve

1шт.

21

31-1862

CLAMP

- P-type, tube

3шт.

22

90-6894T1

SUPPORT

BRACKET - clamp mounting, tube support

1шт.

23

413-612

BOLT,Hex, 3/8" - 16 x 3/4", Gr 5

1шт.

24

425-106

NUT,3/8"-16, Cl 5

1шт.

25

SM8121240

BOLT

BOLT - hex, 12 - 1.75 x 40 mm

1шт.

34

90-7554T91

MASTER CYLINDER

CYLINDER ASSEMBLY - brake master, parts list Figure 7-022

1шт.

35

REF

INSTRUCTION

CABLE - parking brake, See Figure 7-008 or 7-009A for correct cable

1шт.
