Артикул
Название
Примечание
Количество
1
60-6109T2
HARNESS
ASSEMBLY - main cab, Includes: Ref. 2
1шт.
2
1301191C1
CONNECTION
RING - lock, connector
2шт.
3
REF
INSTRUCTION
BRACKET - mounting, circuit breaker (See Figure 4-10)
1шт.
4
60-6301T1
HARNESS
ASSEMBLY - relay power
1шт.
5
31-1348
CLAMP
- retaining
1шт.
6
25709R1
WASHER
- flat, 13/32 x 13/16 x 3/32 inch, hardened
1шт.
7
232-4136
LOCK NUT,3/8"-16, GC
NUT - hex, lock, 3/8 inch NC
1шт.
8
REF
INSTRUCTION
FLASHER ASSEMBLY - time base (See Figure 4-58)
1шт.
9
60-6027T1
SENSOR
ASSEMBLY - proximity (See Figure 6-38)
1шт.
10
182-528
SCREW,Sl Pan Hd, #10 - 32 x 1/2"
- machine, pan, No. 10 NF x 1/2 inch
8шт.
12
19-481
SERRATED NUT
- keps, No. 10 NF
8шт.
13
20-1451T1
BLOCK
- junction
1шт.
14
20-2340T91
IGNITION SWITCH
SWITCH - micro, clutch (See Figure 6-44)
1шт.
16
1964752C1
SWITCH
- lighting
1шт.
17
22-823
MOUNT
MOUNT - adhesive back, strap
1шт.
18
22-824
CABLE TIE,3/16" x 7 1/4"
STRAP - tie, 7 inch
1шт.
19
50-2962T1
CONDUIT
PROTECTOR - flexguard (Order S119717 and, Serial Range: cut-length)
1шт.
20
60-6059T91
IGNITION SWITCH
SWITCH - mode lever (See Figure 6-34)
1шт.
21
32-161
COLLAR CLAMP
CLAMP - retaining
1шт.
22
113-3
BOLT,Hex, 1/4" - 20 x 3/4", Gr 5
1шт.
23
19-105
WASHER,1/4", SAE
- flat, 1/4 inch
1шт.
24
280129
NUT,1/4"-20
NUT - hex lock, 1/4 inch NC
2шт.
25
REF
INSTRUCTION
CONTROLLER ASSEMBLY - transmission (See Figure 6-32)
1шт.
26
REF
INSTRUCTION
PLATE - relay mounting (See Figure 4-12)
1шт.
30
19-2
BOLT,Hex, 1/4" - 20 x 1", Gr 5
- hex, 1/4 NC x 1 inch
1шт.
31
19-5564
LOCK NUT,#6-32, GB
NUT - hex lock, No. 6 NC
12шт.
32
19-5577
LOCK WASHER
- lock, 3/8 inch
1шт.
33
115772
NUT
- hex, brass, 3/8 inch NC
1шт.
34
19-115
LOCK WASHER,1/4"
1/4"
1шт.
35
425-104
NUT,1/4"-20, Cl 5
- hex, 1/4 inch NC
1шт.
36
22-766
GROMMET
- protective
1шт.
37
195-102
WASHER,1/4"
- flat, 5/16 x 3/4 x 1/16 inch
1шт.
38
60-6127T1
CONNECTION
LOCK RING - connector
1шт.
39
20-2316T1
SWITCH
- park brake (See Figure 7-4)
1шт.
40
19-6216
SCREW - tapping, hex, No. 8 NC x 1 inch
1шт.
Выбрано товаров: 36
