Артикул
Название
Примечание
Количество
1
90-6123T1
AIR INTAKE TUBE,4" OD
TUBE - rubber, air intake to engine
1шт.
2
90-6972T1
BRACKET
- air cleaner mounting
1шт.
3
90-6520T1
ELBOW
- rubber
1шт.
4
90-6118T1
BRACKET
- air cleaner mounting
1шт.
5
AIR CLEANER ASSEMBLY - engine (See Fig. 4-62)
1шт.
6
90-6121T1
BRAKE BAND
CLAMP - air cleaner mounting (Includes Refs. 43 and 44)
2шт.
7
19-17
BOLT,Hex, 3/8" - 16 x 1", Gr 5, Full Thd
CAPSCREW, 3/8 UNC x 1 G-5
5шт.
8
19-78
SPECIAL NUT,3/8"-16, G5
3/8 UNC G-B
6шт.
9
19-107
WASHER
- flat, 3/8
2шт.
10
29-111
DIPSTICK
INDICATOR - filter service
1шт.
11
90-4681T1
FLANGE
- indicator mounting
1шт.
12
19-1
BOLT,Hex, 1/4" - 20 x 3/4", Gr 5
CAPSCREW, 1/4 UNC x 3/4 G-5
2шт.
13
19-76
NUT,1/4"-20, G5
1/4 UNC G-B
2шт.
14
31-2388
FITTING
- barbed, 1/8 NPT male x 1/8 hose
2шт.
15
31-605
HYD CONNECTOR,1/8"-27 NPTF, Female
COUPLING, 1/8 NPT female x 1/8 NPT female
1шт.
16
40-1091
BOLT,Hex, M10 x 1.5 x 20mm, Gr 8.8
CAPSCREW, M10 x 1.5 x 20 MM
6шт.
17
90-6240T1
PLATE
BRACKET - air cleaner mounting
1шт.
18
90-6241T1
CLAMP
- air cleaner mounting (Includes refs. 43 and 44)
1шт.
19
19-6
BOLT,5/16" - 18 x 3/4", Gr 5
CAPSCREW, 5/16 UNC x 3/4 G-5
4шт.
20
19-700
WASHER,5/16"
- flat, 3/8
4шт.
21
19-77
NUT,5/16"-18, G5
5/16 UNC G-B
4шт.
22
31-2268
HOSE CLAMP,5.25/6.125 HD Worm, W/liner
CLAMP - intake hose, 5-1/4 to 6-1/8
2шт.
23
32-26
HOSE CLAMP,#28, 1.31/2.25 Type F Worm
CLAMP - aspirator tube, 1-5/16 to 2-1/4
4шт.
24
31-2594
HOSE,1.25" ID x 4.00"
Aspirator Tube; Order 01-4569T1, and Cut to Required Length 1.25" ID x 4.00"
2шт.
25
90-6117T1
TUBE,4" OD x 3" L
- adapter
1шт.
26
90-6004T1
INTAKE AIR HOSE,5.00" ID x 19.88", SAE 2DA712A26B36F17
5.00" ID x 19.88", SAE 2DA712A26B36F17
1шт.
27
90-6119T1
SHIELD
- heat
1шт.
28
90-6277T1
BRACKET
- indicator mounting
1шт.
29
32-146
CLAMP,#108, 4.25"-4.56", T-Bolt
- intake elbow, 4-1/4 to 4-9/16
4шт.
30
90-6521T1
TUBE,1.25" OD
- aspirator
1шт.
31
90-6522T1
SHIELD
- heat
1шт.
32
32-343
MOUNTING CLIP
CLAMP - tube (31-1348) (A)
1шт.
33
31-2694
HOSE,4.78 mm ID x 1219.20 mm
INTAKE AIR HOSE - Air Cleaner to Service Indicator 4.78 mm ID x 1219.20 mm
1шт.
34
22-628
CABLE CLIP
CLAMP - hose
1шт.
35
40-1231
BOLT,Hex, M8 x 1.25 x 16mm, Gr 8.8
CAPSCREW - M8 x 1.25 x 16 MM
4шт.
36
18-633
COLLAR CLAMP
CLAMP - hose
1шт.
37
19-19
BOLT,Hex, 3/8" - 16 x 1 1/2", Gr 5
CAPSCREW, 3/8 UNC x 1-1/2 G-5
1шт.
38
19-380
SPACER, 3/8 x 1-1/2 x 5/8 thk
1шт.
39
19-118
LOCK WASHER,7/16"
7/16"
6шт.
40
19-116
LOCK WASHER,5/16"
5/16"
4шт.
41
40-1087
BOLT,M6 x 20mm
CAPSCREW, M6 x 1 x 20 MM
1шт.
42
32-343
MOUNTING CLIP
CLAMP - hose
1шт.
43
19-39
BOLT,5/16" - 18 x 1 3/4", Gr 5
CAPSCREW, 5/16 UNC x 1-3/4 G-5
3шт.
44
19-508
LOCK NUT
- lock, 5/16 UNC G-B
3шт.
45
90-6834T1
FOAM
1шт.
46
40-1146
BOLT,Hex, M8 x 1.25 x 30mm, Cl 10.9
CAPSCREW, M8 x 1.25 x 30 MM
3шт.
47
90-6873T1
SPACER
STRAP - spacer
1шт.
Выбрано товаров: 47
