Запчасти Case IH 9110 (01-10) - DELUXE OVERHEAD DOOR (10) - CAB

1

BREAKER ASSEMBLY - circuit (See Fig. 2-13)

1шт.

2

60-4027T2

DOOR

- console (60-4027T1)

1шт.

Old part can be used on all tractors, new part should be used when stock is depleted.

1шт.

3

60-5923T1

NOISE PROTECTION

INSULATION - door (Gray)

1шт.

60-4028T1

INSULATOR

INSULATION - door (Tan)

1шт.

4

1964752C1

SWITCH

- rocker, master light (20-1968T1)

1шт.

Old part can be used on all tractors, new part should be used when stock is depleted.

1шт.

5

1964751C1

SWITCH

- rocker, ether start (1-6154)

1шт.

Old part can be used on all tractors, new part should be used when stock is depleted.

1шт.

This rocker switch will only be used with the ether start option

1шт.

6

245012C1

SWITCH

- rocker, dome light, front outlet, rear outlet and dash lights (Quantity 3 without ROPS post gauges)

4шт.

7

60-3210T1

PLUG

- switch hole (Quantity 2 with ether start option, quantity 1 without ROPS post gauges)

3шт.

8

60-5910T1

DECAL

- overhead (With gray interiors and 8 rocker switch openings)

1шт.

60-4031T3

DECAL

- overhead (With tan interiors and 6 rocker switch openings)

1шт.

9

60-4032T2

PANEL

- rocker switch, Start Serial: 17900707

1шт.

Old part can be used prior to serial number break only. When stock is depleted, use new on all.

1шт.

60-4032T1

PANEL

- rocker switch, Serial Range: -17900707

1шт.

Old part can be used prior to serial number break only. When stock is depleted, use new on all.

1шт.

10

60-5928T1

COVER

- console door, (Gray)

1шт.

60-4009T1

COVER

- console door, (Tan)

1шт.

11

19-5621

LOCK NUT,#8-32, GB

NUT - lock, no. 8 UNC G-A

8шт.

12

363-30812

SCREW,Hex Wash Hd, #8-32 x 3/4"

- machine, no. 8 UNC x 3/4

8шт.

13

60-4033T1

BUTTON

KNOB ASSEMBLY

2шт.

14

19-572

SCREW,Sl Pan Hd, #10 - 32 x 1/2", Gr 5

MACHINE SCREW, no. 10 UNF x 1/2

4шт.

15

19-481

SERRATED NUT

- Keps, no. 10 UNF G-A

4шт.

16

20-1451T1

BLOCK

JUNCTION BLOCK

1шт.

17

60-4034T1

HINGE

- console door

1шт.

18

9419000

BOLT,Hex, 1/4" - 20 x 1/2", Gr 5, Full Thd

CAPSCREW, 1/4 UNC x 1/2 G-5

3шт.

19

19-1081

LOCK NUT

- lock, 1/4 UNC G-A

3шт.

20

2-7333T1

WASHER

RING - snap (19-6130)

2шт.

Old part must not be used in this area only. Is OK elsewhere when shown.

1шт.

21

19-6126

SPACER

2шт.

22

19-105

WASHER,1/4", SAE

- flat, 1/4

3шт.
