Запчасти Case IH QUADTRAC 620 (48.138.AB[05]) - FRONT IDLER, BSN ZFF304747 (48) - TRACKS & TRACK SUSPENSION

Схема запчастей Case IH QUADTRAC 620 - (48.138.AB[05]) - FRONT IDLER, BSN ZFF304747 (48) - TRACKS & TRACK SUSPENSION
4
9
8
7
3
10
5
6
1
48.138.ab 06
2
3
1

Артикул

Название

Примечание

Количество

1

371884A1

BEARING CONE,63.5mm ID x 30.24mm W

4шт.

2

84234874

HUB

Idler

2шт.

3

371878A1

BEARING CUP,112.71mm OD x 23.81mm W

Front Idler

4шт.

4

87387720

RETAINER

Bearing

2шт.

5

84303553

BOLT,Hex, M20 x 2.5 x 60mm, Cl 10.9

2шт.

6

84573723

SEAL

Oil Idler

2шт.

7

238-5426

O-RING,0.275" Thk x 4.625" ID, -426, Cl 5, 75 Duro

2шт.

8

87408174

CAP

Idler, Steel

2шт.

8

47608296

COVER

Idler, Clear

2шт.

9

370014

SNAP RING,M130, Internal

2шт.

10

246406A1

PLUG,M12 x 1.5 ORB

Used with Steel Cap

2шт.

10

86598043

PLUG,M12 x 1.5 ORB

Used with Clear Cap

2шт.

Выбрано товаров: 12
