Запчасти Case IH QUADTRAC 580 (90.100.AE[02]) - HOOD PIVOT FRAME, 20TH ANNIVERSARY EDITION (90) - PLATFORM, CAB, BODYWORK AND DECALS

1

47805508

SUPPORT

Hood Pivot

1шт.

2

87711882

NYLON BEARING,15.9mm ID x 17.45mm OD x 29.34mm L

4шт.

3

47554727

PIVOT

Hood Plate

1шт.

4

47873501

SUPPORT

Hood

1шт.

5

87711881

BOLT,M12 x 1.75 x 100mm

2шт.

6

896-15010

WASHER,11mm ID x 24mm OD x 3mm Thk

6шт.

7

627-10035

BOLT,Hex, M10 x 1.5 x 35mm, Cl 10.9, Full Thd

8шт.

8

47548705

BRACKET

Assy, RH, Pre-Cleaner

1шт.

9

627-10025

BOLT,Hex, M10 x 1.5 x 25mm, Cl 10.9, Full Thd

2шт.

10

427218A1

INSERT

Threaded

2шт.

11

829-1410

NUT,M10 x 1.5, Cl 10.9

4шт.

12

84561096

GAS STRUT

Hood Support

2шт.

13

896-11010

WASHER,11mm ID x 21mm OD x 2.5mm Thk

8шт.

14

408566A1

INSERT,M8

4шт.

15

896-15012

WASHER,13.5mm ID x 28mm OD x 4mm Thk

4шт.

16

43436

FLANGE NUT,M12

4шт.

17

47878790

CAP

12mm OD x 58mm L

4шт.

18

84295992

FOAM

Radiator Top

1шт.
