Запчасти Case IH QUADTRAC 500 (21.105.BL[06]) - TRANSMISSION LUBRICATION LINES, REAR, 470, 500 HD, 540 HD, ASN ZFF308001 (21) - TRANSMISSION

Схема запчастей Case IH QUADTRAC 500 - (21.105.BL[06]) - TRANSMISSION LUBRICATION LINES, REAR, 470, 500 HD, 540 HD, ASN ZFF308001 (21) - TRANSMISSION
3
20
4
30
19
9
13
7
33
25
2
24
10
4
15
11
23
6
3
5
5
14
29
33
35
3
11
15
18
6
10
8
34
30
33
31
28
1
12
21.105.bc
32
3
16
27
22
17
26
21

Артикул

Название

Примечание

Количество

1

47461768

HOSE

Filter To Transmission Regulator

1шт.

2

47798823

BRACKET

Transmission Hose Support

1шт.

3

372453A1

BLOCK

Tube Mounting

2шт.

4

367658A1

PLATE

Clamp Cover

2шт.

5

895-18010

WASHER,10.5mm ID x 18mm OD x 1.6mm Thk

4шт.

6

827-10075

BOLT,Hex, M10 x 1.5 x 75mm, Cl 10.9

4шт.

7

895-11016

WASHER,17.5mm ID x 30mm OD x 3mm Thk

2шт.

8

627-16025

BOLT,Hex, M16 x 2 x 25mm, Cl 10.9, Full Thd

2шт.

9

47605519

FILTER HEAD

Single

1шт.

10

86579698

90 ELBOW,1 3/16"-12 ORFS x M33 x 2 ORB

Incl 30, 33

2шт.

11

895-11010

WASHER,11mm ID x 20mm OD x 2mm Thk

8шт.

12

627-10025

BOLT,Hex, M10 x 1.5 x 25mm, Cl 10.9, Full Thd

4шт.

13

47806883

TUBE

Transmission Lube, Suction, PS4

1шт.

14

427140A1

HOSE,50.80 mm ID x 101.60 mm

1шт.

15

47757203

HOSE CLAMP,60.3mm - 68.3mm, Spring

2шт.

16

700-105

HYD CONNECTOR,1-7/16" - 12 Male ORFS x M33 x 2 Male ORB

Incl 31, 33

1шт.

17

87340823

HYD CONNECTOR

Incl 32

1шт.

18

87646809

TUBE,46.23 mm L

1шт.

19

87646822

BRACKET

Retainer Fill Cap Lock

1шт.

20

325737A1

CAP

Locking

1шт.

21

84319553

HOSE

Filler, Formed

1шт.

22

832-10410

NUT,M10 x 1.5, Cl 8

2шт.

23

627-10035

BOLT,Hex, M10 x 1.5 x 35mm, Cl 10.9, Full Thd

2шт.

24

L18331

CABLE TIE,375.9mm L, Nylon, Black

1шт.

25

47745305

CLAMP

4" Split Flange

2шт.

26

426-1028

BOLT,Hex, 5/8" - 11 x 1-3/4", Gr 8

4шт.

27

87016953

O-RING,0.139" Thk x 3.859" ID, -241, Cl 5, 75 Duro

1шт.

28

214-1520

HOSE CLAMP,#20, 0.81" - 1.75", Type F Worm, W/ Liner

1шт.

29

214-1528

HOSE CLAMP,#28, 1.31" - 2.25", Type F Worm, W/ Liner

1шт.

30

9991976

O-RING,0.07" Thk x 0.739" ID, -18, Cl 6, 90 Duro

2шт.

31

9824050

O-RING,0.07" Thk x 0.926" ID, -21, Cl 6, 90 Duro

1шт.

32

86598105

O-RING,2.9mm Thk x 38.6mm ID, Cl 6, 90 Duro

1шт.

33

86598104

O-RING,2.9mm Thk x 29.6mm ID, Cl 6, 90 Duro

3шт.

34

47822912

HYDRAULIC HOSE

Transmission Filter Supply, PS4

1шт.

35

390618A1

INSERT,Knurled Open, M10 x 13.46mm OD

4шт.

Выбрано товаров: 35
