(48.130.02) - TRACK DRIVE WHEEL SCRAPER

Запчасти Case IH QUADTRAC 500 (48.130.02) - TRACK DRIVE WHEEL SCRAPER (48) - TRACKS & TRACK SUSPENSION

Схема запчастей Case IH QUADTRAC 500 - (48.130.02) - TRACK DRIVE WHEEL SCRAPER (48) - TRACKS & TRACK SUSPENSION
3
7
home
5
1
6
5
3
6
6
2
2
4
7
7
7
6
4
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

1

87439068

PLATE

Drive Wheel Scraper

4шт.

2

87439069

BAR

Scraper Retention

8шт.

3

896-15020

WASHER,22mm ID x 44mm OD x 5mm Thk

8шт.

4

827-20080

BOLT,Hex, M20 x 2.5 x 80mm, Cl 10.9

8шт.

5

87428948

BUMPER,58mm ID x 115mm OD x 5mm Thk

Undercarriage, Rubber

8шт.

6

896-11012

WASHER,13.5mm ID x 24mm OD x 3mm Thk

16шт.

7

86836488

HEX SOC SCREW,M12 x 25mm, Cl 12.9

16шт.
