Запчасти Case IH QUADTRAC 500 (25.100.29) - AXLE LUBE MANIFOLD - 500 & 600 SERIES AXLES (25) - FRONT AXLE SYSTEM

1

428862A1

MANIFOLD

Axle Lube

1шт.

2

238-5110

O-RING,0.103" Thk x 0.362" ID, -110, Cl 5, 75 Duro

1шт.

3

221576A1

PLUG,Hex Soc, M14 x 1.5, ORB

Incl 4

1шт.

4

637-63113

O-RING,2.2mm Thk x 11.3mm ID, Cl 6

1шт.

5

221579A1

PLUG,M22 x 1.5 ORB

Incl 6

1шт.

6

637-63193

O-RING,2.2mm Thk x 19.3mm ID, Cl 6, 90 Duro

1шт.

7

895-11010

WASHER,11mm ID x 20mm OD x 2mm Thk

3шт.

8

828-10075

BOLT,Hex, M10 x 1.5 x 75mm, Cl 10.9

1шт.

9

628-10035

BOLT,Hex, M10 x 1.5 x 35mm, Cl 10.9, Full Thd

2шт.

10

238-5122

O-RING,0.103" Thk x 1.11" ID, -122, Cl 5, 75 Duro

2шт.

11

218-5211

PLUG,Hex Soc, 7/8"-14 ORB

Incl 12

1шт.

12

237-6010

O-RING,0.097" Thk x 0.755" ID, -910, Cl 6, 90 Duro

1шт.
