Артикул
Название
Примечание
Количество
1
700-305
ELBOW,90 Degree Elbow, 13/16" - 16 Male ORFS x M18 x 1.5 Male ORB
Incl 6, 36
3шт.
2
47456219
SHIM,45mm ID x 76.2mm OD x 2.14mm Thk
4шт.
3
701-452
TEE,13/16" - 16 Male ORFS x 13/16" - 16 Male ORFS x 13/16" - 16 Male ORFS
Incl 6
2шт.
4
364967A1
TEE,13/16" - 16 Male ORFS x M18 x 1.5 Male ORB x M14 x 1.5 Female ORB
Incl 6, 36
1шт.
5
178889A1
DIAGNOSTIC COUPLER
Steering
1шт.
6
238-6014
O-RING,0.07" Thk x 0.489" ID, -14, Cl 6, 90 Duro
12шт.
7
701-903
NUT,13/16" - 16
4шт.
8
827-8065
BOLT,Hex, M8 x 1.25 x 65mm, Cl 10.9
2шт.
10
84577088
STEERING CYLINDER,Double Acting, 50mm Rod, 568.7mm Stroke
Articulation
2шт.
84577088R
Reman Cyl Articulation
REMAN-HYD CYLINDER
2шт.
84577088C
Return Number
CORE-HYD CYLINDER
1шт.
11
D95143
WIPER SEAL,44.42mm ID x 57.17mm OD x 7.92mm Thk
16шт.
12
217-429
PLUG,Hex Soc, 1/8" - 27 NPTF
4шт.
13
219-36
LUBE NIPPLE,45 Degree Elbow, 1/8" - 27 NPTF
2шт.
14
217-1014
ELBOW,1/8" - 27 Female x 1/8" - 27 Male
2шт.
15
70-6013T2
PIN
Headed, Steering Cylinder
4шт.
16
70-5967T1
SPACER,16.7mm ID x 22.2mm OD x 11.2mm
8шт.
17
496-21066
WASHER,16.6mm ID x 33.5mm OD x 3.8mm Thk
8шт.
18
87563128
LOCK BOLT,Hex, M16 x 2 x 35mm, Cl 8.8, Full Thd
8шт.
19
219-20
LUBE NIPPLE,1/4" - 28
2шт.
20
F53473
LOCK NUT,1/8-27 NPSM
2шт.
21
1339090C1
HOSE
Grease Line, 838mm L
2шт.
22
70-6076T3
PIN
Mounting, 1-3/4" x 7-1/4"
2шт.
23
70-6085T2
PIN
Mounting, 1-3/4" x 9-1/2"
2шт.
24
832-10408
NUT,M8 x 1.25, Cl 8.8
2шт.
25
895-11008
WASHER,9mm ID x 16mm OD x 1.6mm Thk
4шт.
26
50-2551T1
CLAMP
Tube
4шт.
27
50-2533T1
PLATE
Cover
4шт.
28
47498735
HOSE ASSY.,12.7mm ID x 550mm L
Steering Control
2шт.
29
47644627
HOSE
Steering Control
2шт.
30
214-1472
HOSE CLAMP,#72, 4.06" - 5", Type F Worm
2шт.
31
391133A1
CLAMP
Hose
2шт.
32
84179121
HYD TUBE,12.70 mm OD
Priority, Steering Cylinder, Right
1шт.
33
84179116
HYD TUBE
Priority, Steering Cylinder, Left
1шт.
34
84162396
HYD TUBE,12.70 mm OD
Steering Pressure, Left
1шт.
35
84182434
HYD TUBE,12.70 mm OD
Steering Pressure, Right
1шт.
37
86598099
O-RING,2.2mm Thk x 11.3mm ID, Cl 6
1шт.
Выбрано товаров: 39
