Артикул
Название
Примечание
Количество
35-1803T92
KIT
- cab, deluxe, order from Machinery Price List, Includes: Ref. 1 - 46
1шт.
1
60-6366T91
HOOD
CONTAINER ASSEMBLY - storage compartment, Includes: Ref. 2
1шт.
2
NSS
NOT SOLD SEPARAT
COVER - storage compartment
1шт.
5
60-6362T91
HOOD
CONTAINER ASSEMBLY - storage compartment, Includes: Ref. 6
1шт.
6
NSS
NOT SOLD SEPARAT
COVER - storage compartment
1шт.
9
60-6370T1
COVER
- door, storage compartment
1шт.
10
60-6369T1
HOOD
COVER - door
1шт.
11
60-6372T2
FLAP
DOOR - storage compartment
1шт.
12
60-6371T2
COVER
- door
1шт.
13
60-6360T1
HINGE
- door
1шт.
14
60-6361T1
HINGE
- door
1шт.
15
60-6358T1
GASKET
TRIM - edge, 63 mm (2-1/2 inch) long, cut from F64277X bulk trim, see below
1шт.
16
60-6359T1
GASKET
TRIM - edge, 194 mm (7-5/8 inch) long, cut from F64277X bulk trim, see below
1шт.
17
60-6374T2
SPRING
- cover
4шт.
18
425-108
NUT,1/2" - 13, Gr 5
NUT, , Hex, Mounting, seat 1/2"-13, G5
6шт.
19
495-11028
WASHER,1/4", SAE
(flat, 9/32 x 5/8 x 1/16") 1/4", SAE
6шт.
20
426-424
BOLT,Hex, 1/4" - 20 x 1-1/2", Gr 8
- hex, 1/4 NC x 1-1/2 inch, grade 8
6шт.
21
60-5920T1
CAP
- trim, gray
12шт.
22
1-8674
CAP WASHER
- trim
12шт.
23
463-3108
SCREW,Hex Wash Hd, #10-24 x 1/2"
- machine, hex washer head, No. 10 NC x 1/2 inch
23шт.
24
193-1004
NUT,Keps, #10 - 24, w/ Ext Tooth LW
NUT - hex, with external tooth lock washer, No. 10 NC
23шт.
25
495-31022
WASHER,#10
20шт.
29
60-6354T2
COVER
- cab post, right-hand rear
1шт.
30
60-6352T2
COVER
- cab post, left-hand rear
1шт.
31
60-6353T1
COVER
- cab post, left-hand front
1шт.
32
60-6355T1
COVER
- cab frame, rear
1шт.
33
3234176R1
COAT HOOK
HOOK - coat
1шт.
34
60-6520T1
PLATE
- coat hook
1шт.
35
280-16516
SELF-TAP SCREW,Hex Wash Hd, #10 x 1"
SCREW - self-tapping, hex washer head, No. 10 - 16 x 1 inch
1шт.
39
1971228C1
VISOR, SUN
VISOR - sun
1шт.
40
60-6521T1
LARGE PLATE
PLATE - mounting, sun visor
1шт.
41
343-11016
SCREW,Cross Flat Hd, #10-24 x 1"
- machine, flat Phillips, No. 10 NC x 1 inch
3шт.
45
60-6531T1
FOAM
SEAL - foam, 292 mm (11-1/2 inch) long, cut from 60-4596T1 bulk seal, see below
2шт.
46
2-3010T1
SPACER
- manual box, hook
1шт.
F64277X
SEAL
TRIM - edge, bulk, 14478 mm (570 inch) long
1шт.
60-4596T1
SEAL
SEAL - foam, bulk, 3048 mm (120 inch) long
1шт.
Выбрано товаров: 36
