Запчасти Case IH PUMA 220 (33.204.AD[01]) - VAR - 337416, 758049 - FRONT AXLE, SUSPENDED, BRAKES (33) - BRAKES & CONTROLS

1

5181994

HOUSING

1шт.

2

5178857

CIRCLIP

2шт.

3

5179560

BUSHING,16.5mm ID x 27mm OD x 27.8mm L

6шт.

4

11200274

BELLEVILLE WASHER,M16 Bolt Size x 34mm OD x 4.4mm Thk

16 x 34 x 4.4

6шт.

5

16334430

BOLT,Hex, M16 x 1.5 x 60mm, Cl 10.9

6шт.

6

5181566

SEAL,198.6mm ID x 205.4mm OD x 3.4mm Thk

1шт.

7

5178850

PISTON RING,Square, 3.4mm Thk x 229.6mm ID, 80 Duro

1шт.

8

5181567

RING

1шт.

9

5182010

HUB,14T Internal / 60T External

1шт.

10

5178813

BRAKE DISC,191mm ID x 266.5mm OD x 4.95mm Thk

1шт.

11

5178903

BRAKE DISC,175mm ID x 247mm OD x 4.5mm Thk

1шт.

12

5181929

BRAKE DISC,182mm ID x 266.5mm OD x 18mm Thk

1шт.
