Запчасти Case IH PUMA 200 (31.114.AH[03]) - VAR - 758031 - PTO 540/1000 RPM, HOUSING (31) - IMPLEMENT POWER TAKE OFF

1

NSS

NOT SOLD SEPARAT

Housing ASSY, Incl 2, 3

1шт.

2

87576362

HOUSING

1шт.

3

44908048

BUSHING,16mm OD x 14mm L

2шт.

4

87347166

SNAP RING,M45 x 3.12mm Thk, Ext

1шт.

5

47132140

SUPPORT

1шт.

6

15540924

SCREW,Hex, M12 x 1.25 x 55mm, Cl 8.8

4шт.

7

11190774

BELLEVILLE WASHER,M12 Bolt Size x 24mm OD x 2.8mm Thk

4шт.

8

47128616

VALVE

ASSY, Incl 9 - 11

1шт.

9

13397370

SNAP RING,M8, Int

1шт.

10

84271074

SPACER,8mm ID x 15.6mm OD x 10mm L

1шт.

11

47128521

VALVE

1шт.
