Запчасти Case IH PUMA 185 (31.114.AH[01]) - VAR - 391141, 758028 - PTO 540E/1000 RPM, HOUSING (31) - IMPLEMENT POWER TAKE OFF

1

87558751

FUEL TANK

ASSY, Incl 2, 3

1шт.

2

NSS

NOT SOLD SEPARAT

Housing, Incl in 1

1шт.

3

44908048

BUSHING,16mm OD x 14mm L

2шт.

4

87347166

SNAP RING,M45 x 3.12mm Thk, Ext

1шт.

5

84295659

SUPPORT

ASSY, Incl 6, 7

1шт.

6

NSS

NOT SOLD SEPARAT

Carrier, Incl in 5

1шт.

7

47127805

BUSHING,12mm ID x 14mm OD x 15mm L

1шт.

8

84271075

VALVE

ASSY, Incl 9 - 11

1шт.

9

13397370

SNAP RING,M8, Int

1шт.

10

84271074

SPACER,8mm ID x 15.6mm OD x 10mm L

1шт.

11

47128521

VALVE

1шт.

12

14453182

O-RING,0.07" Thk x 0.489" ID, -14, Cl 9, 70 Duro

1шт.

13

5196030

PIN,20mm OD x 16.5mm L

1шт.

14

47127897

SNAP RING,M21.5, Ext

1шт.

15

10118540

PLUG,M10 x 1 x 11, Brass

2шт.

16

14437585

O-RING,8.00mm ID x 1.50mm

2шт.

17

84281722

SPRING,Compression, 15mm OD x 80mm L

1шт.

18

47127951

CAP COVER

1шт.

19

13420576

SNAP RING,M16, Int

1шт.

20

11190774

BELLEVILLE WASHER,M12 Bolt Size x 24mm OD x 2.8mm Thk

4шт.

21

15540924

SCREW,Hex, M12 x 1.25 x 55mm, Cl 8.8

4шт.
