Запчасти Case IH PUMA 165 (55.680.AO[01]) - VAR - 758802, 758803, 758804 - GPS RECEIVER, SUPPORT (55) - ELECTRICAL SYSTEMS

1

87634999

SUPPORT

ASSY, Incl 2, 8 - 12

1шт.

2

87308870

LATCH

1шт.

3

87652569

INSERT,M6 x 14 mm L

3шт.

4

81869856

WASHER,6mm ID x 17mm OD

Roof, 6 x 17

3шт.

5

86505530

BOLT,Hex, M6 x 1 x 20mm, Cl 10.9, Full Thd

3шт.

6

12647604

WASHER,6.15mm ID x 16mm OD x 2mm Thk

3шт.

7

10615479

LOCK WASHER,6.4mm ID x 11mm OD x 0.7mm Thk

3шт.

8

87308841

RIVET,Pop, 3.97mm OD x 10.79mm L

3шт.

9

87641584

MULTIPOLE CONNECTOR,12 Pole

1шт.

10

87634998

SUPPORT

1шт.

11

84058832

CLIP

1шт.

12

86508947

LINCH PIN,18.8mm OD

1шт.

13

82034114

SPACER,M6 x 25mm L

3шт.
