Запчасти Case IH PUMA 165 (90.150.AE) - VAR - 391183 - 391184 - CAB, MOUNT, FRONT (90) - PLATFORM, CAB, BODYWORK AND DECALS

Схема запчастей Case IH PUMA 165 - (90.150.AE) - VAR - 391183 - 391184 - CAB, MOUNT, FRONT (90) - PLATFORM, CAB, BODYWORK AND DECALS
15
2
8
7
13
15
12
16
1
7
9
11
5
14
14
6
11
13
3
5
17
90.150.ac (01)
6
10
12
18
4
9

Артикул

Название

Примечание

Количество

1

84353066

SUPPORT

RH, ASSY, Incl 14, 16

1шт.

Valid for PUMA 150, PUMA 165

1шт.

1

84353061

SUPPORT

RH, ASSY, Incl 14, 16

1шт.

Valid for PUMA 150 CVT, PUMA 165 CVT, PUMA 180 CVT, PUMA 150 CVX, PUMA 165 CVX, PUMA 180 CVX

1шт.

2

84353071

SUPPORT

LH, ASSY, Incl 14, 17

1шт.

3

84177681

SUPPORT

LH

1шт.

4

84177692

SUPPORT

RH

1шт.

Valid for PUMA 150, PUMA 165

1шт.

4

84177691

SUPPORT

RH

1шт.

Valid for PUMA 150 CVT, PUMA 165 CVT, PUMA 180 CVT, PUMA 150 CVX, PUMA 165 CVX, PUMA 180 CVX

1шт.

5

16043424

SCREW,Hex, M8 x 1.25 x 20mm, Cl 8.8, Full Thd

2шт.

6

384197

BOLT,Hex, M20 x 2.5 x 150mm, Cl 8.8

2шт.

7

9706694

NUT,Hex, M20, Cl 8

2шт.

8

84337830

SUPPORT

1шт.

9

47630557

WASHER,Nordlock NL14; 15.2mm ID x 23mm OD x 3.4mm Thk

8шт.

10

16214621

SCREW,Hex, M14 x 1.5 x 50mm, Cl 8.8

4шт.

11

9780073

BOLT,Hex, M20 x 2.5 x 110mm, Cl 8.8

4шт.

12

86511327

WASHER,21mm ID x 37mm OD x 3mm Thk

2шт.

13

11191974

BELLEVILLE WASHER,M22 Bolt Size x 42mm OD x 5mm Thk

2шт.

14

87396965

INSULATOR,100mm OD x 85.3mm L

2шт.

15

12646704

WASHER,8.15mm ID x 20mm OD x 2mm Thk

2шт.

16

NSS

NOT SOLD SEPARAT

Support, RH, Incl in 1

1шт.

17

NSS

NOT SOLD SEPARAT

Support, LH, Incl in 2

1шт.

18

15977934

SCREW,Hex, M14 x 1.5 x 90mm, Cl 10.9

M14 x 1.5 x 90

4шт.

Valid for PUMA 150, PUMA 165

1шт.

18

16214621

SCREW,Hex, M14 x 1.5 x 50mm, Cl 8.8

4шт.

Valid for PUMA 150 CVT, PUMA 165 CVT, PUMA 180 CVT, PUMA 150 CVX, PUMA 165 CVX, PUMA 180 CVX

1шт.
