Запчасти Case IH PUMA 200 CVT (90.150.AE[02]) - VAR - 391183 - 391184 - CAB, MOUNT, FRONT (90) - PLATFORM, CAB, BODYWORK AND DECALS

1

84353501

SUPPORT

RH, ASSY, Incl 14, 20

1шт.

2

84353506

SUPPORT

LH, ASSY, Incl 14, 19

1шт.

3

84140750

YOKE

LH

1шт.

4

84140756

YOKE

RH

1шт.

5

47619390

INSULATING PLATE

2шт.

6

384197

BOLT,Hex, M20 x 2.5 x 150mm, Cl 8.8

2шт.

7

9706694

NUT,Hex, M20, Cl 8

2шт.

8

47619387

PAD

2шт.

9

47630557

WASHER,Nordlock NL14; 15.2mm ID x 23mm OD x 3.4mm Thk

8шт.

10

11360221

BOLT,Hex, M14 x 1.5 x 100, 8.8

4шт.

11

16214621

SCREW,Hex, M14 x 1.5 x 50mm, Cl 8.8

4шт.

12

86511327

WASHER,21mm ID x 37mm OD x 3mm Thk

2шт.

13

11191974

BELLEVILLE WASHER,M22 Bolt Size x 42mm OD x 5mm Thk

2шт.

14

87396965

INSULATOR,100mm OD x 85.3mm L

2шт.

15

12646704

WASHER,8.15mm ID x 20mm OD x 2mm Thk

2шт.

16

87737521

SCREW,Hex, M20 X 120, 8.8

M20 x 120

4шт.

17

84337809

BRACKET

1шт.

18

16043424

SCREW,Hex, M8 x 1.25 x 20mm, Cl 8.8, Full Thd

2шт.

19

NSS

NOT SOLD SEPARAT

Support, LH, Incl in 2

1шт.

20

NSS

NOT SOLD SEPARAT

Support, RH, Incl in 1

1шт.
