Запчасти Case IH PUMA 185 CVT (90.154.AE[01]) - CAB DOOR, HINGE, LH, 1 DOOR (90) - PLATFORM, CAB, BODYWORK AND DECALS

1

87301643

HINGE

LH

1шт.

2

11087971

CIRCLIP,M8

2шт.

3

82029160

PIN,9.8MM OD X 117.6MM L

Lower

1шт.

4

82029159

PIN,9.8mm OD x 129mm L

Upper

1шт.

5

14496501

WASHER,8.4mm ID x 17mm OD x 1.6mm Thk

4шт.

6

16044021

SCREW,Hex, M8 x 1.25 x 40mm, Cl 8.8

2шт.

7

87528178

SEALING WASHER,20mm ID x 60mm OD x 5.5mm Thk

Door Hinge

6шт.

8

15213321

BOLT,Hex, M8 x 1.25 x 35mm, Cl 8.8

2шт.

9

44995004

WASHER,9mm ID x 60mm OD x 3.4mm Thk

2шт.

10

16100811

NUT,Hex, M8, 6.80mm, Cl 8, ZND

4шт.

11

5132136

CAP COVER,M8

M8

4шт.

12

82027697

BUSHING,9.5mm ID x 18mm OD x 17mm L

1шт.
