(90.102.AD[02]) - VAR - 391216, 758207, 758208, 758210, 758951 - ENGINE HOOD, SUPPORT

Запчасти Case IH PUMA 165 CVT (90.102.AD[02]) - VAR - 391216, 758207, 758208, 758210, 758951 - ENGINE HOOD, SUPPORT (90) - PLATFORM, CAB, BODYWORK AND DECALS

Схема запчастей Case IH PUMA 165 CVT - (90.102.AD[02]) - VAR - 391216, 758207, 758208, 758210, 758951 - ENGINE HOOD, SUPPORT (90) - PLATFORM, CAB, BODYWORK AND DECALS
90.102.ad (01)
2
10
5
3
4
8
8
1
7
9
3
9
7
1
1
6
4
3
3
90.100.au (01)
10.202.ah (01)
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

1

9804277

FLANGE NUT,Hex, M8 x 1.25, Cl 8

8шт.

2

87612108

PANEL

Hood Front

1шт.

3

83952214

BALL STUD,M8 x 29.5mm OAL

4шт.

4

82036570

GAS STRUT

2шт.

5

14059421

FLANGE NUT,Hex, M10 x 1.25, Cl. 10

M10 x 1.25

2шт.

6

87353681

HINGE

1шт.

7

82026318

COTTER PIN,1/8 x 2 5/16

1/8 x 2 5/16

2шт.

8

86511324

WASHER,13mm ID x 24mm OD x 2.5mm Thk

2шт.

9

87353680

PIN,12.2mm OD x 44mm L

2шт.

10

84153356

PLATE

1шт.

Выбрано товаров: 10
