(90.120.0101[03]) - DELUXE AIR SEAT WITH SEAT BELT - BREAKDOWN

Запчасти Case IH PUMA 230 (90.120.0101[03]) - DELUXE AIR SEAT WITH SEAT BELT - BREAKDOWN (90) - PLATFORM, CAB, BODYWORK AND DECALS

Схема запчастей Case IH PUMA 230 - (90.120.0101[03]) - DELUXE AIR SEAT WITH SEAT BELT - BREAKDOWN (90) - PLATFORM, CAB, BODYWORK AND DECALS
6
9
2
11
9
14
9
13
11
11
3
8
3
8
8
10
5
11
9
9
3
6
7
3
home
6
8
4
9
12
9
8
1
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

1

84155767

SEAT

ASSY, See Also Page 01,02

1шт.

2

87529810

SUSPENSION

Suspension ASSY

1шт.

3

82020847

KIT

Suspension Shock Absorber

1шт.

4

87529828

HOUSING

Lower Housing

1шт.

5

82020819

KIT

Air Spring

1шт.

6

82030804

KIT

Compressor W/Heating

1шт.

7

82020846

KIT

Suspension Scissors

1шт.

8

82020830

SERVICE KIT

Suspension Fore/Aft Damper

1шт.

9

82020845

SERVICE KIT

Bumper and Roller

1шт.

10

82020844

KIT

Upper Housing

1шт.

11

87529817

KIT

Air Line

1шт.

12

82020843

KIT

Suspension Boot

1шт.

13

82021020

SERVICE KIT

Fore/Aft Isolator

1шт.

14

87529792

HARNESS

1шт.
