Артикул
Название
Примечание
Количество
1
47434172
HYD VALVE SECTION
ASSY, Auxiliary, Left, Incl 2 - 40
1шт.
1
47434172R
REMAN-HYD VALVE
Auxiliary, Left
1шт.
1
47434172C
CORE-VALVE HYD
Return Number
1шт.
2
47426874
PLUG,7/8" - 14
ASSY, Incl 3, 35
1шт.
3
237-6010
O-RING,0.097" Thk x 0.755" ID, -910, Cl 6, 90 Duro
1шт.
4
218-5211
PLUG,Hex Soc, 7/8"-14 ORB
ASSY, Incl 5, 37
1шт.
5
237-6010
O-RING,0.097" Thk x 0.755" ID, -910, Cl 6, 90 Duro
1шт.
6
47422966
SEAL,23.52mm ID x 1.78mm Thk
4шт.
7
47499455
SPOOL
ASSY, Main, Incl 9 - 12
1шт.
7
47499468
SPOOL
ASSY, Auxiliary Main Black, Incl 9 - 12
1шт.
7
47499476
SPOOL
ASSY, Auxiliary Main White, Incl 9 - 12
1шт.
8
237-6002
O-RING,0.064" Thk x 0.239" ID, -902, Cl 6, 90 Duro
1шт.
9
NSS
NOT SOLD SEPARAT
Spool, Incl in 7
1шт.
10
47426760
PLUG,5/16" - 24
ASSY, Incl 8, 39
1шт.
11
47423002
SPRING,17.6mm OD x 45.86mm L
1шт.
12
87437168
WASHER,11.75mm ID x 21mm OD x 1.5mm Thk
2шт.
13
47434055
SPOOL,15.9mm ID x 18.75mm OD x 133.6mm L
Pressure
1шт.
14
436854A1
SPRING,15.11mm OD x 63.35mm L
1шт.
15
87648631
PIN,8mm OD x 19mm L
1шт.
16
87648596
SPRING,3.81mm OD x 23.19mm L
1шт.
17
47434056
SOLENOID
ASSY, Valve, Incl 18 - 22, 29
1шт.
18
NSS
NOT SOLD SEPARAT
Block, Solenoid Adapter Plate, Incl in 17
1шт.
19
NSS
NOT SOLD SEPARAT
Solenoid, Incl in 17
1шт.
20
14304324
HEX SOC SCREW,M5 x 20mm, Cl 8.8, Full Thd
4шт.
21
87714123
FILTER
100 - 150 Micron
1шт.
25
87437167
VALVE SPRING,8.08mm ID x 10.92mm OD x 53.27mm L
2шт.
26
87329482
VALVE BODY
ASSY, EH Pilot, Incl 27 - 32
1шт.
29
282836A1
PLUG,4mm OD x 4mm L
Expansion, 4mm
1шт.
(Qty 8) Incl in 47434056, (Qty 2) Incl in 87329482
1шт.
30
282839A1
PLUG,8mm OD x 8.5mm L
Expansion
1шт.
31
864-8065
HEX SOC SCREW,M8 x 65mm, Cl 8.8
6шт.
32
NSS
NOT SOLD SEPARAT
Body, Incl in 26
1шт.
33
87648607
PLUG,M12 x 1.5 ORB
ASSY, Load Sense, Incl 34, 36
1шт.
34
637-63093
O-RING,2.2mm Thk x 9.3mm ID, Cl 6, 90 Duro
1шт.
35
NSS
NOT SOLD SEPARAT
Plug, Incl in 2
1шт.
36
NSS
NOT SOLD SEPARAT
Plug, Incl in 33
1шт.
37
NSS
NOT SOLD SEPARAT
Plug, Incl in 4
1шт.
38
NSS
NOT SOLD SEPARAT
Body, Incl in 1
1шт.
39
87437101
EXPANSION PLUG,Hex, 6.31mm ID x 15.5mm OD x 48.5mm L
Extension
1шт.
40
84579020
PLUG,1.81" - 2.75"
Extension, 4mm
5шт.
Выбрано товаров: 46
