Запчасти Case IH PUMA 230 (35.120.0103[01]) - TELESCOPIC LINK ENDS - IMPLEMENT CARRIER WITH TELESCOPIC LINK ENDS (VAR.720881-728237) (35) - HYDRAULIC SYSTEMS

1

47137110

LOWER LINK

1шт.

2

47137111

LIFT LINK END ASSY

1шт.

3

47137134

LATCH

2шт.

4

10979421

SCREW,Hex, M6 x 10mm, Cl 8.8

4шт.

5

47137135

LIFT ARM

1шт.

6

47137113

LIFT LINK END ASSY

1шт.

7

47137112

LIFT ARM

RH, Contains Ref. 3-6

1шт.

8

87355020

PIN

1шт.

9

822483

PIN,25.5mm OD x 137mm L

1шт.

10

5166585

LOCK PIN,11mm OD

1шт.

10

5132146

PIN

2шт.

11

84311417

SUPPORT

2шт.

VAR.728237 Hyd. Top Link for All Linkage Options

1шт.

12

84385467

LIFTING ROD

2шт.

VAR.728237 Hyd. Top Link for All Linkage Options

1шт.

13

47137109

LIFT ARM

Contains Ref. 1-4

1шт.

14

47123097

BUSHING,25.7mm ID x 32mm OD x 51mm L

1шт.

15

87707450

TOP LINK

1шт.

16

87317296

PIN,28mm OD x 122.5mm L

Contains Ref. 18

2шт.

17

82034728

SET SCREW,Hex, M10 x 1.25 x 22mm, Cl 8.8

2шт.

18

13406911

LUBE NIPPLE,Straight, 1/4"-28 x 0.54"

2шт.

19

47123096

BUSHING,28.7mm ID x 37mm OD x 45mm L

2шт.
