Запчасти Case IH PUMA 200 (33.224.0101[17]) - ABS SYSTEM - PNEUMATIC TRAILER BRAKE - CONTROL VALVE SUPPORT BRACKETS (VAR. 743965) (33) - BRAKES & CONTROLS

Схема запчастей Case IH PUMA 200 - (33.224.0101[17]) - ABS SYSTEM - PNEUMATIC TRAILER BRAKE - CONTROL VALVE SUPPORT BRACKETS (VAR. 743965) (33) - BRAKES & CONTROLS
7
home
3
4
2
6
5
1

Артикул

Название

Примечание

Количество

1

16043621

BOLT,Hex, M8 x 1.25 x 25mm, Cl 8.8, Full Thd

4шт.

2

10571779

LOCK WASHER,Helical Spring, 8.10mm ID x 14.80mm OD x 2.00mm, ZNM

4шт.

3

12646701

WASHER,8.15mm ID x 20mm OD x 2mm Thk

4шт.

4

84157689

SUPPORT

1шт.

5

10902421

SCREW,Hex, M6 x 20mm, Cl 8.8

2шт.

6

14496401

WASHER,M6.4 x 12.00mm x 1.60mm

2шт.

7

87554135

SUPPORT

1шт.

Выбрано товаров: 7
