Запчасти Case IH PUMA 170 (21.105.01[02]) - TRANSMISSION LUBRICATION SYSTEM - MANIFOLD - BREAKDOWN (VAR.743042-743142) (21) - TRANSMISSION

1

87676058

MANIFOLD

ASSY, Contains Ref. 2-19

1шт.

2

86597760

HYD CONNECTOR,1"-14 ORFS x M2 x 2.0 ORB

Contains Ref. 16,17

1шт.

3

NSS

NOT SOLD SEPARAT

1шт.

4

87723783

SOLENOID VALVE

Contains Ref. 14,15,19

1шт.

5

86598043

PLUG,M12 x 1.5 ORB

Contains Ref. 18

2шт.

6

9993143

HYD CONNECTOR,11/16" - 16 ORFS x 9/16" - 18 ORB

Contains Ref. 11,12

1шт.

7

87676103

HYD CONNECTOR

Contains Ref. 13

1шт.

8

5194826

BRACKET

1шт.

9

14305124

HEX SOC SCREW,M6 x 12mm, Cl 8.8, Full Thd

2шт.

10

14457880

O-RING,0.103" Thk x 0.987" ID, -120, Cl 5, 75 Duro

1шт.

11

9993141

O-RING,0.07" Thk x 0.364" ID, -12, Cl 6, 90 Duro

07 x .364 126

1шт.

12

9617873

O-RING,0.078" Thk x 0.468" ID, -906, Cl 6, 90 Duro

078 x 468 906 6

1шт.

13

5185511

O-RING,1.78mm Thk x 12.42mm ID, 85 Duro

1шт.

14

5185512

O-RING,0.07" Thk x 0.614" ID, -16, Cl 6, 90 Duro

1шт.

15

14438185

O-RING,24mm ID x 3mm

3.0 x 24

1шт.

16

9992069

O-RING,0.07" Thk x 0.614" ID, -16, Cl 6, 90 Duro

07 x .614 166

1шт.

17

86598103

O-RING,2.9mm Thk x 23.6mm ID, Cl 6, 90 Duro

2.9W x 23.6 Green

1шт.

18

86598098

O-RING,2.2mm Thk x 9.3mm ID, Cl 6, 90 Duro

2.2W x 9.3

1шт.

19

5185513

O-RING,1.78mm Thk x 18.77mm ID, 85 Duro

1шт.
