(35.160.04[01]) - VAR - 330926 - FRONT HPL - TUBES FROM MECHANICAL REMOTE VALVES

Запчасти Case IH PUMA 160 (35.160.04[01]) - VAR - 330926 - FRONT HPL - TUBES FROM MECHANICAL REMOTE VALVES (35) - HYDRAULIC SYSTEMS

Схема запчастей Case IH PUMA 160 - (35.160.04[01]) - VAR - 330926 - FRONT HPL - TUBES FROM MECHANICAL REMOTE VALVES (35) - HYDRAULIC SYSTEMS
35.204.03
35.204.01
35.204.05.01
35.204.07.02
35.204.07.01
35.204.05.02
3
5
4
2
4
home
35.160.04 02
6
1
5
3
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

1

84152532

HYDRAULIC HOSE,2260.00mm

Raise

1шт.

2

84159105

HYDRAULIC HOSE,2260.00mm

Lower

1шт.

3

5185524

HYD CONNECTOR

Incl 4, 5

2шт.

4

9992069

O-RING,0.07" Thk x 0.614" ID, -16, Cl 6, 90 Duro

2шт.

5

5135738

O-RING,0.103" Thk x 0.674" ID, -115, 80 Duro

2шт.

6

83972881

COUPLING

2шт.

Выбрано товаров: 6
