(37.100.09) - VAR - 331954 - SLIDER TOW HOOK WITH FIXED D3 TYPE COUPLING, LESS SWINGING DRAWBAR (ITALY)

Запчасти Case IH PUMA 145 (37.100.09) - VAR - 331954 - SLIDER TOW HOOK WITH FIXED D3 TYPE COUPLING, LESS SWINGING DRAWBAR (ITALY) (37) - HITCHES, DRAWBARS & IMPLEMENT COUPLINGS

Схема запчастей Case IH PUMA 145 - (37.100.09) - VAR - 331954 - SLIDER TOW HOOK WITH FIXED D3 TYPE COUPLING, LESS SWINGING DRAWBAR (ITALY) (37) - HITCHES, DRAWBARS & IMPLEMENT COUPLINGS
4
1
3
3
2
home
27.100.01 01
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

1

82027419

TOW HOOK

Cat D3

1шт.

2

87734325

FRAME

, Serial Range: -C6978

1шт.

3

16220874

BOLT,Hex, M18 x 1.5 x 45mm, Cl 12.9

10шт.

4

84351258

FRAME

, Start Serial: D6978

1шт.
