(55.512.01) - BRAKE SYSTEM AND CLUTCH PEDAL SWITCHES

Запчасти Case IH PUMA 130 (55.512.01) - BRAKE SYSTEM AND CLUTCH PEDAL SWITCHES (55) - ELECTRICAL SYSTEMS

Схема запчастей Case IH PUMA 130 - (55.512.01) - BRAKE SYSTEM AND CLUTCH PEDAL SWITCHES (55) - ELECTRICAL SYSTEMS
18.100.01
2
2
33.202.01 (01a)
1
3
33.202.02
1
1
2
4
home
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

1

82026949

PUSH BUTTON SWITCH

Brake

4шт.

2

82880745

SCREW,Phillips Drive, Pan HD, M4 x 16mm, Cl 4.8

6шт.

3

87605245

POTENTIOMETER,4000 Ohm, 13.5 VDC

Rotary Position Sensor

1шт.

4

84224890

BOLT,Hex, M5 x 30mm, Cl 8.8

2шт.

Выбрано товаров: 4
