(35.100.BI[01]) - HYDRAULIC POWER LIFT - CYLINDER AND PINS

Запчасти Case IH PUMA1854 (35.100.BI[01]) - HYDRAULIC POWER LIFT - CYLINDER AND PINS (35) - HYDRAULIC SYSTEMS

Схема запчастей Case IH PUMA1854 - (35.100.BI[01]) - HYDRAULIC POWER LIFT - CYLINDER AND PINS (35) - HYDRAULIC SYSTEMS
5
2
1
4
6
5
37.110.aq
21.110.ac
4
3
35.100.bi 02
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

1

5185964

PIN,34.7mm OD x 132mm L

2шт.

2

5186171

PIN

Assy

2шт.

3

13406911

LUBE NIPPLE,Straight, 1/4"-28 x 0.54"

1шт.

4

12601474

WAVE WASHER,Wave, 10.50mm ID x 21.00mm OD x 0.80mm, 3.00mm, CST, DAC

4шт.

5

82034728

SET SCREW,Hex, M10 x 1.25 x 22mm, Cl 8.8

4шт.

6

47130987

HYDRAULIC CYLINDER,Double Acting, 50mm Rod, 228mm Stroke

Assy, Capacity 7200 KG, VAR.232

2шт.
