Запчасти Case IH PUMA1804 (35.120.AA[01]) - IMPLEMENT CARRIER (35) - HYDRAULIC SYSTEMS

1

47137104

LOWER LINK

RH, Incl 3

1шт.

2

47137107

LOWER LINK

LH, Incl 4

1шт.

3

5189332

HOOK

Assy

2шт.

4

47137106

LIFT LINK END ASSY

RH

1шт.

5

5116063

ROPE,4500mm L

1шт.

6

44017710

BUSHING,37mm ID x 64mm OD x 44.7mm L

2шт.

6

44017819

BUSHING,28.7mm ID x 64mm OD x 44.7mm L

2шт.

7

5130779

ECCENTRIC,11mm OD, Shaft Diameter 29.00mm

2шт.

7

5130780

ECCENTRIC,15.5mm OD, Shaft Diameter 37.00mm

2шт.

8

87355020

PIN

1шт.

9

5174402

LINK CHAIN,1500mm L

1шт.

10

5116059

BUSHING,25.4mm ID x 60mm OD x 51mm L

1шт.

10

5116060

BUSHING,32mm ID x 60mm OD x 51mm L

1шт.

11

822483

PIN,25.5mm OD x 137mm L

1шт.

11

44015196

PIN,31.75mm OD x 146mm L

1шт.

12

87317296

PIN,28mm OD x 122.5mm L

Incl 17

2шт.

13

81862738

PLUG,M38 x 28 x 5mm

1шт.

13

82024718

PANEL

1шт.

14

82034728

SET SCREW,Hex, M10 x 1.25 x 22mm, Cl 8.8

2шт.

15

84253931

LIFT LINK

2шт.

16

5166585

LOCK PIN,11mm OD

1шт.

17

80714

LUBE NIPPLE,1/4"-28 NPT x .54" lg

2шт.
