(90.105.BP[02]) - MID-MOUNT CONTROL VALVE, COVER

Запчасти Case IH PUMA1654 (90.105.BP[02]) - MID-MOUNT CONTROL VALVE, COVER (90) - PLATFORM, CAB, BODYWORK AND DECALS

Схема запчастей Case IH PUMA1654 - (90.105.BP[02]) - MID-MOUNT CONTROL VALVE, COVER (90) - PLATFORM, CAB, BODYWORK AND DECALS
5
2
6
1
4
3
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

1

84121783

COVER

Less

1шт.

2

11701711

NUT,Hex, M10, Cl 8, ZND

3шт.

3

16040821

BOLT,Hex, M10 x 1.5 x 40mm, Cl 8.8, Full Thd

3шт.

4

12626201

WASHER,10.2mm ID x 25mm OD x 3mm Thk

6шт.

5

84122671

TRIM,128mm L

Protector Moulding Cover

1шт.

6

82036856

MOLDING,355mm L

Seal, Hood Latch Bracket

1шт.

Выбрано товаров: 6
