(10.400.BF[02]) - RADIATOR DUCT, SEAL

Запчасти Case IH PUMA 2304 (10.400.BF[02]) - RADIATOR DUCT, SEAL (10) - ENGINE

Схема запчастей Case IH PUMA 2304 - (10.400.BF[02]) - RADIATOR DUCT, SEAL (10) - ENGINE
1
3
5
6
2
7
9
8
10.400.be
4
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

1

82039110

SEAL

Hood to Radiator Side

2шт.

2

87380756

FOAM INSULATION

Seal, Radiator Side to Hood, Serial Range: Side-Hood

2шт.

3

82038264

SEAL,510mm x 15mm x 5mm

1шт.

4

16043221

BOLT,Hex, M8 x 16mm, Cl 8.8, Full Thd

2шт.

5

10519604

WASHER,8.15mm ID x 17mm OD x 2mm Thk

2шт.

6

82030145

FOAM INSULATION

Radiator Air Side

2шт.

7

87565399

SHROUD

1шт.

8

10523401

WASHER,6.15mm ID x 18mm OD x 2mm Thk

8шт.

9

87377778

SCREW,Hex, M6 x 16mm, Cl 8.8

8шт.
