Запчасти Case IH PUMA 230 (55.130.AA[01]) - RIGHT LIFT ROD AND TOP LINK HYDRAULIC ADJUST W/ELECTRONIC CONTROL - SOLENOID VALVES (55) - ELECTRICAL SYSTEMS

1

84361958

HOLDER

Incl 8, 9, 11, 12

1шт.

2

87681589

SPACER,8mm ID x 11mm OD x 16mm L

2шт.

3

14496501

WASHER,8.4mm ID x 17mm OD x 1.6mm Thk

7шт.

4

15213321

BOLT,Hex, M8 x 1.25 x 35mm, Cl 8.8

2шт.

4

16044021

SCREW,Hex, M8 x 1.25 x 40mm, Cl 8.8

2шт.

5

84126831

CONTROL MONITOR

DISPLAY

1шт.

6

13276017

SCREW,Pozidriv Pan Hd, M6 x 12mm, Cl 5.8, Full Thd

4шт.

7

10519407

WASHER,6.4mm ID x 11.95mm OD x 1.6mm Thk

4шт.

8

86511823

SCREW,Phillips Drive, Pan HD, M4 x 8mm, Cl 4.8

2шт.

9

87565290

LAMP

1шт.

10

5132136

CAP COVER,M8

2шт.

11

84340967

SUPPORT

1шт.

12

84174905

WIRE HARNESS

1шт.
