Артикул
Название
Примечание
Количество
1
47434177
HYD VALVE SECTION
ASSY, Hitch Valve, Incl 2 - 46
1шт.
1
47434177R
REMAN-HYD VALVE
Hitch Valve
1шт.
1
47434177C
CORE-VALVE HYD
Return Number
1шт.
2
NSS
NOT SOLD SEPARAT
Valve Body, Incl in 1
1шт.
3
1542563C1
KIT
ASSY, Logic, Incl 4 - 8
1шт.
4
1994580C1
PLUG
Logic Check
1шт.
5
1543329C1
VALVE POPPET,7mm ID x 13.8mm OD x 27mm L
Logic Check
1шт.
6
1994581C1
SPRING,6.1mm OD x 31.1mm L
Logic Check
1шт.
7
238-6015
O-RING,0.07" Thk x 0.551" ID, -15, Cl 6, 90 Duro
1шт.
8
G108723
RING,14.34mm ID x 16.94mm OD x 1.32mm Thk
Back-up
1шт.
11
47379782
SOLENOID,M19 x 1 x 115mm L
ASSY, Cartridge, Incl 40, 45
2шт.
12
337425A3
VALVE, PRESSURE RELI
ASSY, 3200 PSI, Incl 13 - 18
1шт.
13
337427A1
VALVE POPPET,2.93/3.5mm ID x 4.17/8mm OD x 37.25mm L
Relief
1шт.
14
337428A1
SEAT
Relief
1шт.
15
337430A1
GUIDE
Spring
1шт.
16
NSS
NOT SOLD SEPARAT
Spring, Relief, Incl in 12
1шт.
17
NSS
NOT SOLD SEPARAT
Stop, Spring, Incl in 12
1шт.
19
436854A1
SPRING,15.11mm OD x 63.35mm L
Compression, Long
1шт.
20
84187247
SPOOL,15.9mm ID x 19.32mm OD x 96mm L
Pressure
1шт.
22
87648631
PIN,8mm OD x 19mm L
Load Sense
1шт.
23
87648596
SPRING,3.81mm OD x 23.19mm L
Aux. Signal Check
1шт.
24
221578A1
PLUG,M18 x 1.5 ORB
ASSY, Incl 38, 42
1шт.
25
87619813
CHECK VALVE,1/2" - 20
ASSY, Incl 26 - 29
1шт.
26
100-2125
SNAP RING,M25, Int
1шт.
27
237-6005
O-RING,0.072" Thk x 0.414" ID, -905, Cl 6, 90 Duro
1шт.
28
NSS
NOT SOLD SEPARAT
Valve, Check, Incl in 25
1шт.
29
NSS
NOT SOLD SEPARAT
Poppet, Orifice, Incl in 25
1шт.
30
87518992
PLUG
ASSY, Orifice, Incl 31 - 32
1шт.
32
NSS
NOT SOLD SEPARAT
Plug, Orifice, Incl in 30
1шт.
33
385520A1
PLUG,Hex, 13.05mm ID x 22.23mm OD x 23.5mm L
ASSY, Check Valve, Incl 34 - 35
1шт.
34
385521A1
PLUG
Check Valve
1шт.
35
237-6008
O-RING,0.087" Thk x 0.644" ID, -908, Cl 6, 90 Duro
1шт.
36
87648607
PLUG,M12 x 1.5 ORB
ASSY, Load Sense, Incl 39 - 43
1шт.
38
637-63113
O-RING,2.2mm Thk x 11.3mm ID, Cl 6
1шт.
39
637-63093
O-RING,2.2mm Thk x 9.3mm ID, Cl 6, 90 Duro
1шт.
40
86637739
O-RING,0.116" Thk x 0.924" ID, -912, Cl 8, 90 Duro
1шт.
41
NSS
NOT SOLD SEPARAT
Plug, Incl in 21
1шт.
42
NSS
NOT SOLD SEPARAT
Plug, Incl in 24
1шт.
43
NSS
NOT SOLD SEPARAT
Plug, Incl in 36
1шт.
44
87695582
ELEC CONNECTOR,Female, 2 Pole
2шт.
45
NSS
NOT SOLD SEPARAT
Solenoid Cartridge, Incl in 11
2шт.
46
221579A1
PLUG,M22 x 1.5 ORB
O-Ring Included
1шт.
Выбрано товаров: 48
