(90.120.0101[03]) - AIR SEAT WITH SEAT BELT - BREAKDOWN

Запчасти Case IH PUMA 215 (90.120.0101[03]) - AIR SEAT WITH SEAT BELT - BREAKDOWN (90) - PLATFORM, CAB, BODYWORK AND DECALS

Схема запчастей Case IH PUMA 215 - (90.120.0101[03]) - AIR SEAT WITH SEAT BELT - BREAKDOWN (90) - PLATFORM, CAB, BODYWORK AND DECALS
9
14
1
8
3
2
7
11
13
home
2
10
1
5
4
2
1
12
1
1
1
6
1
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

1

82020822

KIT

Bumper and Roller

1шт.

2

82020812

KIT

Knobs

1шт.

3

84155794

SEAT

1шт.

4

82020820

KIT

1шт.

5

82020823

KIT

Suspension Scrissors

1шт.

6

87529861

KIT

Compressor

1шт.

7

82020819

KIT

1шт.

8

87529828

HOUSING

1шт.

9

82020824

SERVICE KIT

Suspension Damper

1шт.

10

87529862

SEAT ACCESSORY

Airline & Fittings

1шт.

11

87529791

HARNESS

Harness

1шт.

12

82020818

BELLOWS

Suspension Boot

1шт.

13

82020825

VALVE

1шт.

14

87529812

SUSPENSION

Suspension

1шт.

Выбрано товаров: 14
