Запчасти Case IH PUMA 200 (33.224.AQ[01]) - PNEUMATIC TRAILER BRAKE - PIPES (33) - BRAKES & CONTROLS

1

82036709

HOSE CLAMP,25mm - 40mm, Worm Gear

1шт.

2

82038494

RIGID TUBE

1шт.

3

82038496

HYD CONNECTOR

1шт.

4

87802837

ELBOW,45 Deg, 7/8-14 x M22 x 1.5 ORB

1шт.

5

2855977

TUBE,485.7 mm Length

1шт.

6

82003206

ELBOW,90 Deg, 7/8-14 x M22 x 1.5 ORB

1шт.

7

86512933

90 ELBOW,90 Degree, 7/16"-20, 37 Degree x 7/16"-20, 37 Degree Fem Sw

1шт.

8

87310442

TUBE,6 mm OD

1шт.

9

82002502

90 ELBOW,7/16"-20 x M10 x 1

1шт.

10

14437585

O-RING,8.00mm ID x 1.50mm

1шт.

11

87802702

HYD CONNECTOR

1шт.

12

81806277

SEAL,20.83mm ID x 31.75mm OD x 8.13mm Thk

1шт.
