Запчасти Case IH PUMA 200 (25.102.AE[02]) - FRONT AXLE - HYDRAULIC DIFFERENTIAL LOCK - CANE VERSION (25) - FRONT AXLE SYSTEM

Схема запчастей Case IH PUMA 200 - (25.102.AE[02]) - FRONT AXLE - HYDRAULIC DIFFERENTIAL LOCK - CANE VERSION (25) - FRONT AXLE SYSTEM
3
5
25.102.au 01
6
23
22
17
7
9
14
2
18
4
20
24
12
15
21
10
24
11
1
16
13
19
8

Артикул

Название

Примечание

Количество

1

5141750

RING GEAR

1шт.

2

5134095

CIRCLIP,200mm ID

1шт.

3

5134083

HOUSING

1шт.

4

11083176

SNAP RING,M125, Ext

1шт.

5

5198090

CLUTCH PLATE,132mm ID x 194mm OD

6шт.

6

5198088

CLUTCH PLATE,119mm ID x 180mm OD

5шт.

7

5135032

HALF-RING,58mm ID x 70mm OD x 4mm Thk

1шт.

8

5134099

HUB

1шт.

9

5144582

DISC,119mm ID x 180mm OD x 15mm Thk

1шт.

10

5134174

ROLLER BEARING,140mm ID x 180mm OD x 5mm W

1шт.

11

5134175

WASHER,140mm ID x 180mm OD x 1mm Thk

1шт.

12

5134093

PLUNGER

1шт.

13

5140120

O-RING,0.103" Thk x 5.737" ID, -162, Cl 5, 75 Duro

1шт.

14

5120761

SPRING,7.7mm OD x 20.5mm L

3шт.

15

14306521

HEX SOC SCREW,M8 x 1.25 x 30mm, Cl 8.8

5шт.

16

10569379

LOCK WASHER

5шт.

17

14452881

O-RING,7.65mm ID x 1.78" Width

1шт.

18

5140121

O-RING,0.103" Thk x 6.737" ID, -166, Cl 5, 75 Duro

1шт.

19

5148467

PIN,6mm OD x 24.5mm L

1шт.

20

5148468

FLANGE

Incl 19

1шт.

21

86579672

HYD CONNECTOR,11/16"-16 ORFS x M16 x 1.5 ORB

Incl 22, 23

1шт.

22

86598100

O-RING,2.2mm Thk x 13.3mm ID, Cl 6, 90 Duro

1шт.

23

9993141

O-RING,0.07" Thk x 0.364" ID, -12, Cl 6, 90 Duro

1шт.

24

5198089

CLUTCH PACK

Incl 5, 6

1шт.

Выбрано товаров: 24
