Запчасти Case IH PUMA 200 (88.035.07[08]) - DIA KIT - FRONT HPL FOR ELECTRONIC/MECHANICAL REMOTES LESS PTO, LESS AUX. COUPLERS - RADIATOR DUCT AND SEALS (88) - ACCESSORIES

1

710062064

Front Linkage for Electronic/Mechanical remote less PTO, less Aux. Coupler, Contains Ref. 2 - 13

1шт.

Refer to Installation Instructions for Correct Assembly Procedure

1шт.

2

82039110

SEAL

2шт.

3

87380756

FOAM INSULATION

2шт.

4

82038278

INSULATOR

, Serial Range: -C7370

1шт.

5

82038425

SEALING STRIP,680mm x 25mm x 10mm

, Serial Range: -C7370

1шт.

6

82038264

SEAL,510mm x 15mm x 5mm

510MM, Rad to Baffle Plate

1шт.

7

16043221

BOLT,Hex, M8 x 16mm, Cl 8.8, Full Thd

2шт.

8

10519604

WASHER,8.15mm ID x 17mm OD x 2mm Thk

2шт.

9

82030145

FOAM INSULATION

Radiator Air Side

2шт.

10

84221833

GASKET

1шт.

11

84546779

BAFFLE

, Serial Range: -C7370

1шт.

12

82038279

SEAL

, Start Serial: D7370

1шт.

13

84543377

DEFLECTOR

ASSY, Incl 14 - 17, Start Serial: D7370

1шт.

14

87649703

DEFLECTOR

2шт.

15

84543379

FOAM

1шт.

16

84543378

BAFFLE

1шт.

17

87635853

STUD,7.1mm D

6шт.
