1
84188828
KNUCKLE,RH
RH, ASSY, Contains Ref. 3
1шт.
2
84188825
KNUCKLE,LH
LH, ASSY, Contains Ref. 3
1шт.
3
5104085
BUSHING,45mm ID x 50mm OD x 30mm L
45 x 50 x 30
2шт.
4
14254434
SCREW,Hex, M14 x 1.5 x 30mm, Cl 10.9, Full Thd
12шт.
5
13407211
LUBE NIPPLE,M10 x 1
3шт.
6
87382384
BALL STUD
BALL PIN
2шт.
7
5137114
SHIM,70.5mm ID x 115mm OD x 0.1mm Thk
1шт.
7
5137115
SHIM,0.15mm Thk
1шт.
7
5137116
SHIM,70.5mm ID x 115mm OD x 0.2mm Thk
0.20 mm THK
1шт.
7
5137117
SHIM,70.5mm ID x 115mm OD x 0.25mm Thk
0.25 mm THK
1шт.
7
5137118
SHIM,70.5mm ID x 115mm OD x 0.3mm Thk
0.30 mm THK
1шт.
8
10717624
THIN NUT,Thin, M18 x 2.5, Cl 05
2шт.
9
87751874
ADJUSTMENT SCREW,M18 x 120mm, Cl 10.9
2шт.
10
5121907
SEAL,70mm ID x 90mm OD x 11mm Thk
3шт.
11
5119660
BALL JOINT,40mm ID x 80mm OD x 24.75mm W
3шт.
12
87355801
SEAL,190mm ID x 220mm OD x 17mm Thk
190X220X15/17
2шт.
13
5133737
ROLLER BEARING,109.5mm ID x 158.75mm OD x 23mm W
109.538 x 158.750 x 23.02
4шт.
14
5141692
NUT,M90 x 2
M90x2
2шт.
15
5100516
WASHER,17mm ID x 32mm OD x 5mm Thk
16шт.
16
10790524
NUT,M16 x 1.5
16шт.
17
87543151
HUB
Contains Ref. 18
2шт.
18
4985063
DOWEL,12mm OD x 20mm L
4шт.
19
87618916
STUD
16шт.
20
87671955
CAP,15.50mm ID x 22.00mm OD x 40.00mm
16шт.
21
87382381
BALL STUD
BALL PIN
1шт.
22
84166643
SEAL,45mm ID x 65mm OD x 27mm Thk
2шт.
