Запчасти Case IH PUMA 195 (1.80.1[01]) - POWER TAKE-OFF 540E/1000 RPM - SHAFT AND GEARS - C6764 (07) - HYDRAULIC SYSTEM

1

26794680

BALL BEARING,70.00mm x 125.00 x 24.00mm

70x125x24

1шт.

2

11076176

SNAP RING,M125, Int

1шт.

3

47132124

CIRCLIP,M70

D=70

1шт.

4

87715987

DRIVING GEAR

1шт.

For PUMA 165, PUMA 180, PUMA 195 Models only

1шт.

4

87592699

DRIVING GEAR

750 rpm

1шт.

For PUMA 210 Model only

1шт.

5

5151437

BUSHING,44.4mm ID x 55mm OD x 35mm L

1шт.

6

87578126

SLEEVE,Z12

1шт.

7

87578128

GEAR,21T Internal / 33T External

1шт.

8

87715988

DRIVING GEAR

1000 rpm

1шт.

For PUMA 165, PUMA 180, PUMA 195 Models only

1шт.

8

87592698

DRIVING GEAR

1000 rpm

1шт.

For PUMA 210 Model only

1шт.

9

5182627

BALL BEARING,40 mm ID x 90 mm OD x 23 mm

40 x 90 x 23

1шт.

For PUMA 165, PUMA 180, PUMA 195 Models only

1шт.

9

5138660

BEARING, ROLLER, CYL,40mm ID x 90mm OD x 23mm W

D=40x90x23

1шт.

For PUMA 210 Model only

1шт.

10

5123114

RING NUT,Hex, M36 x 1.5

M36 x 1.5

1шт.

11

47131852

RETAINER,70.5mm ID x 86mm OD x 4mm Thk

D=70

1шт.

12

5196487

OIL SEAL,80.00mm ID x 100.00 OD x 10.00mm

80 x 100 x 10

1шт.

13

87347166

SNAP RING,M45 x 3.12mm Thk, Ext

1шт.

14

47130743

PTO SHAFT,6T Splines, 182mm L

540 RPM

1шт.

14

47130744

PTO SHAFT,21T, 20T, 182mm L

1000 RPM, 21 teeth

1шт.

14

47132584

PTO SHAFT

1000 RPM, 1-3/4", 20 teeth

1шт.

20 Spline 1"3/4 Shaft, VAR.792

1шт.

15

5182629

ANTI-WRAP PLATE

1шт.

16

5179204

PLUG,20.27mm OD x 6.38mm W

1шт.

17

47131841

SHAFT

1шт.

18

14459881

O-RING,2.237" ID x 2.443" OD x 0.103"

2.62x56.82

1шт.
