Запчасти Case IH PUMA 195 (1.87.4/ C) - DYNAMIC FRONT FENDERS - BREAKDOWN (08) - SHEET METAL

1

87748073

HUB

ASSY, RH, Serial Range: -C6345

1шт.

1

87748074

HUB

ASSY, LH, Serial Range: -C6345

1шт.

1

84179112

HUB

ASSY, RH, Start Serial: D6345

1шт.

1

84179113

HUB

ASSY, LH, Start Serial: D6345

1шт.

2

87744045

SUPPORT

, Serial Range: -C6345

2шт.

2

84179111

SUPPORT

, Start Serial: D6345

2шт.

3

47132634

NUT,M18, 1.5mm Pitch

M18x1.5

1шт.

4

14489601

WASHER,19mm ID x 34mm OD x 3mm Thk

D=19

1шт.

5

87543521

HUB

1шт.

6

47132633

SCREW,M18 x 1.5, Cl 8.8

M18x1.5

1шт.

7

87748071

LOCKING PLATE

RH

1шт.

7

87748072

LOCKING PLATE

LH

1шт.

8

11198579

BELLEVILLE WASHER,M10 Bolt Size x 20mm OD x 1.9mm Thk

1шт.

9

11306924

BOLT,Hex, M10 x 1.25 x 30, 8.8, Full Thd

M10 x 1.5 x 30

1шт.

10

87543520

BASE

1шт.

11

87543524

SPACER,45mm

4шт.

12

14496901

WASHER,17mm ID x 30mm OD x 3mm Thk

D=17

4шт.

13

11254121

BOLT,Hex, M16 x 80, 8.8

4шт.

14

47132629

LOCK NUT,M25 x 1.5 ZG

1шт.

15

47132631

DOWEL,M14 x 1.5mm

1шт.

16

10791311

THIN NUT,M14 x 1.5, Cl 04

1шт.

17

11191079

BELLEVILLE WASHER,Belleville, 15mm ID x 27mm OD x 2.6mm Thk

1шт.

18

47132625

COVER

1шт.

19

26799930

TAPERED BEARING,25mm ID x 52mm OD x 16.25mm W

25 x 52 x 16.25

2шт.
