Запчасти Case IH PUMA 185 (35.100.0201[02A]) - FRONT AXLE WITH ACTIVE SUSPENSIONS - HYDRAULIC DIFFERENTIAL LOCK - BREAKDOWN - D7091 (VAR.720463-743963-743964) (35) - HYDRAULIC SYSTEMS

Схема запчастей Case IH PUMA 185 - (35.100.0201[02A]) - FRONT AXLE WITH ACTIVE SUSPENSIONS - HYDRAULIC DIFFERENTIAL LOCK - BREAKDOWN - D7091 (VAR.720463-743963-743964) (35) - HYDRAULIC SYSTEMS
17
13
12
23
25
14
20
9
21
5
18
9
3
2
19
10
4
1
11
26
24
home
7
6
22
28
29
15
8
27
16

Артикул

Название

Примечание

Количество

1

87593447

VALVE SECTION

ASSY

1шт.

2

NSS

NOT SOLD SEPARAT

1шт.

3

87639753

KIT

ASSY, Contains Ref. 2,4

1шт.

4

NSS

NOT SOLD SEPARAT

1шт.

5

87639735

KIT

Contains Ref. 26,27

1шт.

6

5185513

O-RING,1.78mm Thk x 18.77mm ID, 85 Duro

1шт.

7

5197118

ELBOW,90 Deg, 1"3/16-12 ORFS x M27 x 2 ORB

Contains Ref. 6,8

1шт.

8

14438185

O-RING,24mm ID x 3mm

1шт.

9

87639734

KIT

2шт.

10

87639720

KIT

Contains Ref. 29

1шт.

11

87639721

KIT

Contains Ref. 28

1шт.

12

14309070

SCREW,M8 x 70mm

M8 x 70

4шт.

13

87545861

POPPET

1шт.

14

87545875

SPRING

1шт.

15

87588853

SNAP RING

1шт.

16

87639738

KIT

Contains Ref. 13-15

1шт.

17

87588852

SOLENOID VALVE

1шт.

87588852R

REMAN-HYD VALVE

PUMA 170, PUMA 185, PUMA 200, PUMA 215 all (12/10-)

1шт.

87588852C

CORE-VALVE HYD

Return Number

1шт.

18

84486704

SOLENOID,12 VDC, 23W, 5.9 Ohm, 210 bar

1шт.

19

87639737

KIT

Contains Ref. 20-24

1шт.

20

87616276

SEALING RING

31 x 2.20

1шт.

21

14457980

O-RING,0.103" Thk x 1.049" ID, -121, Cl 5, 75 Duro

1шт.

22

87545843

SCREW,M6 x 1.25 x 1.25mm

1шт.

23

87616275

SEALING RING

15 x 2.20

1шт.

24

577567

O-RING,9.92mm ID x 15.16mm OD x 2.62mm

2.62 x 9.92

2шт.

25

NSS

NOT SOLD SEPARAT

1шт.

26

NSS

NOT SOLD SEPARAT

1шт.

27

NSS

NOT SOLD SEPARAT

1шт.

28

NSS

NOT SOLD SEPARAT

1шт.

29

NSS

NOT SOLD SEPARAT

1шт.

Выбрано товаров: 31
